C++性能提示

除新增批量接口外，此举还简化了新批量变体的签名：经测试客户端仅需判断是否找到所有键值，因此可直接返回布尔值而非Status对象。

memory_manager.h

class MemoryManager {
 public:
  ...
  util::StatusOr<LiveTensor> Lookup(const TensorIdProto& id);

class MemoryManager {
 public:
  ...
  util::StatusOr<LiveTensor> Lookup(const TensorIdProto& id);

  // Lookup the identified tensors
  struct LookupKey {
    ClientHandle client;
    uint64 local_id;
  };
  bool LookupMany(absl::Span<const LookupKey> keys,
                  absl::Span<tensorflow::Tensor> tensors);

object_store.h

template <typename T>
class ObjectStore {
 public:
  ...
  absl::Status DeleteRef(Ref);

template <typename T>
class ObjectStore {
 public:
  ...
  absl::Status DeleteRef(Ref);

  // Delete many references.  For each ref, if no other Refs point to the same
  // object, the object will be deleted.  Returns non-OK on any error.
  absl::Status DeleteRefs(absl::Span<const Ref> refs);
  ...
template <typename T>
absl::Status ObjectStore<T>::DeleteRefs(absl::Span<const Ref> refs) {
  util::Status result;
  absl::MutexLock l(&mu_);
  for (auto ref : refs) {
    result.Update(DeleteRefLocked(ref));
  }
  return result;
}

memory_tracking.cc

void HandleBatch(int, const plaque::Batch& input) override {
  for (const auto& t : input) {
    auto in = In(t);
    PLAQUE_OP_ASSIGN_OR_RETURN(const auto& handles, in.handles());
    for (const auto handle : handles.value->handles()) {
      PLAQUE_OP_RETURN_IF_ERROR(in_buffer_store_
                                    ? bstore_->DeleteRef(handle)
                                    : tstore_->DeleteRef(handle));
    }
  }
}

void HandleBatch(int, const plaque::Batch& input) override {
  for (const auto& t : input) {
    auto in = In(t);
    PLAQUE_OP_ASSIGN_OR_RETURN(const auto& handles, in.handles());
    if (in_buffer_store_) {
      PLAQUE_OP_RETURN_IF_ERROR(
          bstore_->DeleteRefs(handles.value->handles()));
    } else {
      PLAQUE_OP_RETURN_IF_ERROR(
          tstore_->DeleteRefs(handles.value->handles()));
    }
  }
}

堆的批量初始化可在 O(N) 时间内完成，而逐个添加元素并在每次添加后更新堆属性则需要 O(N lg(N)) 时间。

每次查找都需要解码包含K条目整区块。将解码后的条目存储在缓存中，后续查找时直接调用缓存。

lexicon.cc

void GetTokenString(int pos, std::string* out) const {
  ...
  absl::FixedArray<LexiconEntry, 32> entries(pos + 1);

  // Decode all lexicon entries up to and including pos.
  for (int i = 0; i <= pos; ++i) {
    p = util::coding::TwoValuesVarint::Decode32(p, &entries[i].remaining,
                                                &entries[i].shared);
    entries[i].remaining_str = p;
    p += entries[i].remaining;  // remaining bytes trail each entry.
  }

mutable std::vector<absl::InlinedVector<std::string, 16>> cache_;
...
void GetTokenString(int pos, std::string* out) const {
  ...
  DCHECK_LT(skentry, cache_.size());
  if (!cache_[skentry].empty()) {
    *out = cache_[skentry][pos];
    return;
  }
  ...
  // Init cache.
  ...
  const char* prev = p;
  for (int i = 0; i < block_sz; ++i) {
    uint32 shared, remaining;
    p = TwoValuesVarint::Decode32(p, &remaining, &shared);
    auto& cur = cache_[skentry].emplace_back();
    gtl::STLStringResizeUninitialized(&cur, remaining + shared);

    std::memcpy(cur.data(), prev, shared);
    std::memcpy(cur.data() + shared, p, remaining);
    prev = cur.data();
    p += remaining;
  }
  *out = cache_[skentry][pos];

rpc-stats.h

static void RecordRPC(const Name &name, const RPC_Stats_Measurement& m);

static void RecordRPC(const Name &name, const RPC_Stats_Measurement& m,
                      WallTime now);

clientchannel.cc

const WallTime now = WallTime_Now();
...
RPC_Stats::RecordRPC(stats_name, m);

const WallTime now = WallTime_Now();
...
RPC_Stats::RecordRPC(stats_name, m, now);

hitless-transfer-phase.cc

TransferPhase HitlessTransferPhase::get() const {
  static CallsiteMetrics cm("HitlessTransferPhase::get");
  MonitoredMutexLock l(&cm, &mutex_);
  return phase_;
}

TransferPhase HitlessTransferPhase::get() const { return phase_; }

hitless-transfer-phase.cc

bool HitlessTransferPhase::AllowAllocate() const {
  static CallsiteMetrics cm("HitlessTransferPhase::AllowAllocate");
  MonitoredMutexLock l(&cm, &mutex_);
  return phase_ == TransferPhase::kNormal || phase_ == TransferPhase::kBrownout;
}

bool HitlessTransferPhase::AllowAllocate() const {
  return phase_ == TransferPhase::kNormal || phase_ == TransferPhase::kBrownout;
}

此前我们采用逐个添加图节点和边的方式构建循环检测数据结构，每条边都需要高昂的计算成本。现改为以逆后序遍历方式一次性添加整个图，使循环检测变得轻而易举。

graphcycles.h

class GraphCycles : public util_graph::Graph {
 public:
  GraphCycles();
  ~GraphCycles() override;

  using Node = util_graph::Node;

class GraphCycles : public util_graph::Graph {
 public:
  GraphCycles();
  ~GraphCycles() override;

  using Node = util_graph::Node;

  // InitFrom adds all the nodes and edges from src, returning true if
  // successful, false if a cycle is encountered.
  // REQUIRES: no nodes and edges have been added to GraphCycles yet.
  bool InitFrom(const util_graph::Graph& src);

graphcycles.cc

bool GraphCycles::InitFrom(const util_graph::Graph& src) {
  ...
  // Assign ranks in topological order so we don't need any reordering during
  // initialization. For an acyclic graph, DFS leaves nodes in reverse
  // topological order, so we assign decreasing ranks to nodes as we leave them.
  Rank last_rank = n;
  auto leave = [&](util_graph::Node node) {
    DCHECK(r->rank[node] == kMissingNodeRank);
    NodeInfo* nn = &r->nodes[node];
    nn->in = kNil;
    nn->out = kNil;
    r->rank[node] = --last_rank;
  };
  util_graph::DFSAll(src, std::nullopt, leave);

  // Add all the edges (detect cycles as we go).
  bool have_cycle = false;
  util_graph::PerEdge(src, [&](util_graph::Edge e) {
    DCHECK_NE(r->rank[e.src], kMissingNodeRank);
    DCHECK_NE(r->rank[e.dst], kMissingNodeRank);
    if (r->rank[e.src] >= r->rank[e.dst]) {
      have_cycle = true;
    } else if (!HasEdge(e.src, e.dst)) {
      EdgeListAddNode(r, &r->nodes[e.src].out, e.dst);
      EdgeListAddNode(r, &r->nodes[e.dst].in, e.src);
    }
  });
  if (have_cycle) {
    return false;
  } else {
    DCHECK(CheckInvariants());
    return true;
  }
}

graph_partitioner.cc

absl::Status MergeGraph::Init() {
  const Graph& graph = *compiler_->graph();
  clusters_.resize(graph.NodeLimit());
  graph.PerNode([&](Node node) {
    graph_->AddNode(node);
    NodeList* n = new NodeList;
    n->push_back(node);
    clusters_[node] = n;
  });
  absl::Status s;
  PerEdge(graph, [&](Edge e) {
    if (!s.ok()) return;
    if (graph_->HasEdge(e.src, e.dst)) return;  // already added
    if (!graph_->InsertEdge(e.src, e.dst)) {
      s = absl::InvalidArgumentError("cycle in the original graph");
    }
  });
  return s;
}

absl::Status MergeGraph::Init() {
  const Graph& graph = *compiler_->graph();
  if (!graph_->InitFrom(graph)) {
    return absl::InvalidArgumentError("cycle in the original graph");
  }
  clusters_.resize(graph.NodeLimit());
  graph.PerNode([&](Node node) {
    NodeList* n = new NodeList;
    n->push_back(node);
    clusters_[node] = n;
  });
  return absl::OkStatus();
}

采用新算法替换死锁检测机制，其运行速度提升约50倍，且可无障碍扩展至数百万个互斥锁(旧算法依赖2K限制避免性能断崖)。新代码基于以下论文：《有向无环图的动态拓扑排序算法》David J. Pearce, Paul H. J. Kelly《实验算法学报》(JEA)JEA主页存档第11卷，2006年，文章编号1.7

新算法仅需 O(|V|+|E|) 空间(旧算法需 O(|V|^2) 位)。由于锁获取顺序图结构极为稀疏，空间消耗大幅降低。该算法结构简洁：核心实现仅需约100行C++代码。由于代码现可支持更大规模互斥量，我们得以解除人为设定的2K限制，从而在实际程序中发现了大量潜在死锁。

基准测试结果：因死锁检测主要在调试模式下启用，故采用DEBUG模式运行。基准测试参数(/2k等)代表追踪节点数量。在旧算法默认2k限制下，新算法每次插入边仅需0.5微秒，而旧算法耗时22微秒。新算法还能轻松扩展至更大规模图结构而不崩溃，旧算法则会迅速崩溃。

DEBUG: Benchmark            Time(ns)    CPU(ns) Iterations
----------------------------------------------------------
DEBUG: BM_StressTest/2k        23553      23566      29086
DEBUG: BM_StressTest/4k        45879      45909      15287
DEBUG: BM_StressTest/16k      776938     777472        817

DEBUG: BM_StressTest/2k          392        393   10485760
DEBUG: BM_StressTest/4k          392        393   10485760
DEBUG: BM_StressTest/32k         407        407   10485760
DEBUG: BM_StressTest/256k        456        456   10485760
DEBUG: BM_StressTest/1M          534        534   10485760

初始代码采用区间映射(IntervalMap)因其似乎是支持相邻块合并的理想数据结构，但哈希表足以胜任——通过哈希表查找即可定位相邻块。此项改进(结合CL中的其他变更)使tpu::BestFitAllocator性能提升约4倍。

best_fit_allocator.h

using Block = gtl::IntervalMap<int64, BlockState>::Entry;
...
// Map of pairs (address range, BlockState) with one entry for each allocation
// covering the range [0, allocatable_range_end_).  Adjacent kFree and
// kReserved blocks are coalesced. Adjacent kAllocated blocks are not
// coalesced.
gtl::IntervalMap<int64, BlockState> block_list_;

// Set of all free blocks sorted according to the allocation policy. Adjacent
// free blocks are coalesced.
std::set<Block, BlockSelector> free_list_;

// A faster hash function for offsets in the BlockTable
struct OffsetHash {
  ABSL_ATTRIBUTE_ALWAYS_INLINE size_t operator()(int64 value) const {
    uint64 m = value;
    m *= uint64_t{0x9ddfea08eb382d69};
    return static_cast<uint64_t>(m ^ (m >> 32));
  }
};

// Hash table maps from block start address to block info.
// We include the length of the previous block in this info so we
// can find the preceding block to coalesce with.
struct HashTableEntry {
  BlockState state;
  int64 my_length;
  int64 prev_length;  // Zero if there is no previous block.
};
using BlockTable = absl::flat_hash_map<int64, HashTableEntry, OffsetHash>;

旧代码检测两个节点是否共享源时，会将每个节点的源按排序顺序获取，然后进行排序交集操作。新代码将一个节点的源放入哈希表，然后遍历另一个节点的源并检查哈希表。

name             old time/op  new time/op  delta
BM_CompileLarge   28.5s ± 2%   22.4s ± 2%  -21.61%  (p=0.008 n=5+5)

location.h

// Hasher for Location objects.
struct LocationHash {
  size_t operator()(const Location* key) const {
    return key != nullptr ? util_hash::Hash(key->address()) : 0;
  }
};

size_t HashLocation(const Location& loc);
...
struct LocationHash {
  size_t operator()(const Location* key) const {
    return key != nullptr ? HashLocation(*key) : 0;
  }
};

location.cc

size_t HashLocation(const Location& loc) {
  util_hash::MurmurCat m;

  // Encode some simpler features into a single value.
  m.AppendAligned((loc.dynamic() ? 1 : 0)                    //
                  | (loc.append_shard_to_address() ? 2 : 0)  //
                  | (loc.is_any() ? 4 : 0)                   //
                  | (!loc.any_of().empty() ? 8 : 0)          //
                  | (loc.has_shardmap() ? 16 : 0)            //
                  | (loc.has_sharding() ? 32 : 0));

  if (loc.has_shardmap()) {
    m.AppendAligned(loc.shardmap().output() |
                    static_cast<uint64_t>(loc.shardmap().stmt()) << 20);
  }
  if (loc.has_sharding()) {
    uint64_t num = 0;
    switch (loc.sharding().type_case()) {
      case Sharding::kModShard:
        num = loc.sharding().mod_shard();
        break;
      case Sharding::kRangeSplit:
        num = loc.sharding().range_split();
        break;
      case Sharding::kNumShards:
        num = loc.sharding().num_shards();
        break;
      default:
        num = 0;
        break;
    }
    m.AppendAligned(static_cast<uint64_t>(loc.sharding().type_case()) |
                    (num << 3));
  }

  auto add_string = [&m](absl::string_view s) {
    if (!s.empty()) {
      m.Append(s.data(), s.size());
    }
  };

  add_string(loc.address());
  add_string(loc.lb_policy());

  // We do not include any_of since it is complicated to compute a hash
  // value that is not sensitive to order and duplication.
  return m.GetHash();
}

graph_splitter.cc

absl::btree_map<std::string, absl::btree_map<std::string, OpDef>> ops;

// The btree maps from {package_name, op_name} to its const Opdef*.
absl::btree_map<std::pair<absl::string_view, absl::string_view>,
                const OpDef*>
    ops;

此前我们采用单层哈希表，其键由路径(字符串)及若干数值子键组成。平均每个路径约出现在1000个键中。现将哈希表拆分为两级：第一级以路径为键，每个二级哈希表仅存储特定路径的子键到数据映射关系。此方案使路径存储内存消耗减少1000倍，同时显著提升了同一路径下批量访问多个子键的操作速度。

rtp_controller.h

const gtl::flat_map<int, int> payload_type_to_clock_frequency_;

// A map (implemented as a simple array) indexed by payload_type to clock freq
// for that paylaod type (or 0)
struct PayloadTypeToClockRateMap {
  int map[128];
};
...
const PayloadTypeToClockRateMap payload_type_to_clock_frequency_;

zone_set.h

class ZoneSet: public dense_hash_set<ZoneId> {
 public:
  ...
  bool Contains(ZoneId zone) const {
    return count(zone) > 0;
  }

class ZoneSet {
  ...
  // Returns true iff "zone" is contained in the set
  bool ContainsZone(ZoneId zone) const {
    return zone < b_.size() && b_.get_bit(zone);
  }
  ...
 private:
  int size_;          // Number of zones inserted
  util::bitmap::InlinedBitVector<256> b_;

基准测试结果：

CPU: AMD Opteron (4 cores) dL1:64KB dL2:1024KB
Benchmark                          Base (ns)  New (ns) Improvement
------------------------------------------------------------------
BM_Evaluate/1                            960       676    +29.6%
BM_Evaluate/2                           1661      1138    +31.5%
BM_Evaluate/3                           2305      1640    +28.9%
BM_Evaluate/4                           3053      2135    +30.1%
BM_Evaluate/5                           3780      2665    +29.5%
BM_Evaluate/10                          7819      5739    +26.6%
BM_Evaluate/20                         17922     12338    +31.2%
BM_Evaluate/40                         36836     26430    +28.2%

hlo_computation.h

using TransitiveOperandMap =
    std::unordered_map<const HloInstruction*,
                       std::unordered_set<const HloInstruction*>>;

class HloComputation::ReachabilityMap {
  ...
  // dense id assignment from HloInstruction* to number
  tensorflow::gtl::FlatMap<const HloInstruction*, int> ids_;
  // matrix_(a,b) is true iff b is reachable from a
  tensorflow::core::Bitmap matrix_;
};

memory_manager.cc

LiveTensor::LiveTensor(tf::Tensor t, std::shared_ptr<const DeviceInfo> dinfo,
                       bool is_batched)
    : tensor(std::move(t)),
      device_info(dinfo ? std::move(dinfo) : std::make_shared<DeviceInfo>()),
      is_batched(is_batched) {

static const std::shared_ptr<DeviceInfo>& empty_device_info() {
  static std::shared_ptr<DeviceInfo>* result =
      new std::shared_ptr<DeviceInfo>(new DeviceInfo);
  return *result;
}

LiveTensor::LiveTensor(tf::Tensor t, std::shared_ptr<const DeviceInfo> dinfo,
                       bool is_batched)
    : tensor(std::move(t)), is_batched(is_batched) {
  if (dinfo) {
    device_info = std::move(dinfo);
  } else {
    device_info = empty_device_info();
  }

embedding_executor_8bit.cc

// The actual implementation of the EmbeddingLookUpT using template parameters
// instead of object members to improve the performance.
template <bool Mean, bool SymmetricInputRange>
static tensorflow::Status EmbeddingLookUpT(...) {
    ...
  std::unique_ptr<tensorflow::quint8[]> zero_data(
      new tensorflow::quint8[max_embedding_width]);
  memset(zero_data.get(), 0, sizeof(tensorflow::quint8) * max_embedding_width);

// A size large enough to handle most embedding widths
static const int kTypicalMaxEmbedding = 256;
static tensorflow::quint8 static_zero_data[kTypicalMaxEmbedding];  // All zeroes
...
// The actual implementation of the EmbeddingLookUpT using template parameters
// instead of object members to improve the performance.
template <bool Mean, bool SymmetricInputRange>
static tensorflow::Status EmbeddingLookUpT(...) {
    ...
  std::unique_ptr<tensorflow::quint8[]> zero_data_backing(nullptr);

  // Get a pointer to a memory area with at least
  // "max_embedding_width" quint8 zero values.
  tensorflow::quint8* zero_data;
  if (max_embedding_width <= ARRAYSIZE(static_zero_data)) {
    // static_zero_data is big enough so we don't need to allocate zero data
    zero_data = &static_zero_data[0];
  } else {
    // static_zero_data is not big enough: we need to allocate zero data
    zero_data_backing =
        absl::make_unique<tensorflow::quint8[]>(max_embedding_width);
    memset(zero_data_backing.get(), 0,
           sizeof(tensorflow::quint8) * max_embedding_width);
    zero_data = zero_data_backing.get();
  }

indexblockdecoder.cc

for (int i = 0; i < ndocs-1; i++) {
  uint32 delta;
  ERRORCHECK(b->GetRice(rice_base, &delta));
  docs_.push_back(DocId(my_shard_ + (base + delta) * num_shards_));
  base = base + delta + 1;
}
docs_.push_back(last_docid_);

docs_.resize(ndocs);
DocId* docptr = &docs_[0];
for (int i = 0; i < ndocs-1; i++) {
  uint32 delta;
  ERRORCHECK(b.GetRice(rice_base, &delta));
  *docptr = DocId(my_shard_ + (base + delta) * num_shards_);
  docptr++;
  base = base + delta + 1;
}
*docptr = last_docid_;

发送约400KB张量的基准测试显示性能提升约10-15%：

Benchmark              Time(ns)    CPU(ns) Iterations
-----------------------------------------------------
BM_RPC/30/98k_mean    148764691 1369998944       1000

Benchmark              Time(ns)    CPU(ns) Iterations
-----------------------------------------------------
BM_RPC/30/98k_mean    131595940 1216998084       1000

index.cc

return search_iterators::DocPLIteratorFactory::Create(opts);

return search_iterators::DocPLIteratorFactory::Create(std::move(opts));

encoded-vector-hits.h

std::stable_sort(hits_.begin(), hits_.end(),
                 gtl::OrderByField(&HitWithPayloadOffset::docid));

struct HitWithPayloadOffset {
  search_iterators::LocalDocId64 docid;
  int first_payload_offset;  // offset into the payload vector.
  int num_payloads;

  bool operator<(const HitWithPayloadOffset& other) const {
    return (docid < other.docid) ||
           (docid == other.docid &&
            first_payload_offset < other.first_payload_offset);
  }
};
    ...
    std::sort(hits_.begin(), hits_.end());

autofdo_profile_utils.h

auto iterator = absl::WrapUnique(sstable->GetIterator());
while (!iterator->done()) {
  T profile;
  if (!profile.ParseFromString(iterator->value_view())) {
    return absl::InternalError(
        "Failed to parse mem_block to specified profile type.");
  }
  ...
  iterator->Next();
}

auto iterator = absl::WrapUnique(sstable->GetIterator());
T profile;
while (!iterator->done()) {
  if (!profile.ParseFromString(iterator->value_view())) {
    return absl::InternalError(
        "Failed to parse mem_block to specified profile type.");
  }
  ...
  iterator->Next();
}

stats-router.cc

for (auto& r : routers_to_update) {
  ...
  ResourceRecord record;
  {
    MutexLock agg_lock(r.agg->mutex());
    r.agg->AddResourceRecordUsages(measure_indices, &record);
  }
  ...
}

ResourceRecord record;
for (auto& r : routers_to_update) {
  ...
  record.Clear();
  {
    MutexLock agg_lock(r.agg->mutex());
    r.agg->AddResourceRecordUsages(measure_indices, &record);
  }
  ...
}

program_rep.cc

std::string DeterministicSerialization(const proto2::Message& m) {
  std::string result;
  proto2::io::StringOutputStream sink(&result);
  proto2::io::CodedOutputStream out(&sink);
  out.SetSerializationDeterministic(true);
  m.SerializePartialToCodedStream(&out);
  return result;
}

absl::string_view DeterministicSerializationTo(const proto2::Message& m,
                                               std::string* scratch) {
  scratch->clear();
  proto2::io::StringOutputStream sink(scratch);
  proto2::io::CodedOutputStream out(&sink);
  out.SetSerializationDeterministic(true);
  m.SerializePartialToCodedStream(&out);
  return absl::string_view(*scratch);
}

为尾部单个ASCII字节添加处理逻辑，而非仅处理四字节倍数。此举可避免对5字节等全ASCII字符串调用较慢的通用处理函数。

utf8statetable.cc

// Scan a UTF-8 stringpiece based on state table.
// Always scan complete UTF-8 characters
// Set number of bytes scanned. Return reason for exiting
// OPTIMIZED for case of 7-bit ASCII 0000..007f all valid
int UTF8GenericScanFastAscii(const UTF8ScanObj* st, absl::string_view str,
                             int* bytes_consumed) {
                             ...
  int exit_reason;
  do {
    //  Skip 8 bytes of ASCII at a whack; no endianness issue
    while ((src_limit - src >= 8) &&
           (((UNALIGNED_LOAD32(src + 0) | UNALIGNED_LOAD32(src + 4)) &
             0x80808080) == 0)) {
      src += 8;
    }
    //  Run state table on the rest
    int rest_consumed;
    exit_reason = UTF8GenericScan(
        st, absl::ClippedSubstr(str, src - initial_src), &rest_consumed);
    src += rest_consumed;
  } while (exit_reason == kExitDoAgain);

  *bytes_consumed = src - initial_src;
  return exit_reason;
}

// Scan a UTF-8 stringpiece based on state table.
// Always scan complete UTF-8 characters
// Set number of bytes scanned. Return reason for exiting
// OPTIMIZED for case of 7-bit ASCII 0000..007f all valid
int UTF8GenericScanFastAscii(const UTF8ScanObj* st, absl::string_view str,
                             int* bytes_consumed) {
                             ...
  int exit_reason = kExitOK;
  do {
    //  Skip 8 bytes of ASCII at a whack; no endianness issue
    while ((src_limit - src >= 8) &&
           (((UNALIGNED_LOAD32(src + 0) | UNALIGNED_LOAD32(src + 4)) &
             0x80808080) == 0)) {
      src += 8;
    }
    while (src < src_limit && Is7BitAscii(*src)) { // Skip ASCII bytes
      src++;
    }
    if (src < src_limit) {
      //  Run state table on the rest
      int rest_consumed;
      exit_reason = UTF8GenericScan(
          st, absl::ClippedSubstr(str, src - initial_src), &rest_consumed);
      src += rest_consumed;
    }
  } while (exit_reason == kExitDoAgain);

  *bytes_consumed = src - initial_src;
  return exit_reason;
}

inlined_vector.h

auto Storage<T, N, A>::Resize(ValueAdapter values, size_type new_size) -> void {
  StorageView storage_view = MakeStorageView();

  IteratorValueAdapter<MoveIterator> move_values(
      MoveIterator(storage_view.data));

  AllocationTransaction allocation_tx(GetAllocPtr());
  ConstructionTransaction construction_tx(GetAllocPtr());

  absl::Span<value_type> construct_loop;
  absl::Span<value_type> move_construct_loop;
  absl::Span<value_type> destroy_loop;

  if (new_size > storage_view.capacity) {
  ...
  } else if (new_size > storage_view.size) {
    construct_loop = {storage_view.data + storage_view.size,
                      new_size - storage_view.size};
  } else {
    destroy_loop = {storage_view.data + new_size, storage_view.size - new_size};
  }

auto Storage<T, N, A>::Resize(ValueAdapter values, size_type new_size) -> void {
  StorageView storage_view = MakeStorageView();
  auto* const base = storage_view.data;
  const size_type size = storage_view.size;
  auto* alloc = GetAllocPtr();
  if (new_size <= size) {
    // Destroy extra old elements.
    inlined_vector_internal::DestroyElements(alloc, base + new_size,
                                             size - new_size);
  } else if (new_size <= storage_view.capacity) {
    // Construct new elements in place.
    inlined_vector_internal::ConstructElements(alloc, base + size, &values,
                                               new_size - size);
  } else {
  ...
  }

tensor_shape.cc

template <class Shape>
TensorShapeBase<Shape>::TensorShapeBase(gtl::ArraySlice<int64> dim_sizes) {
  set_tag(REP16);
  set_data_type(DT_INVALID);
  set_ndims_byte(0);
  set_num_elements(1);
  for (int64 s : dim_sizes) {
    AddDim(internal::SubtleMustCopy(s));
  }
}

template <class Shape>
void TensorShapeBase<Shape>::InitDims(gtl::ArraySlice<int64> dim_sizes) {
  DCHECK_EQ(tag(), REP16);

  // Allow sizes that are under kint64max^0.25 so that 4-way multiplication
  // below cannot overflow.
  static const uint64 kMaxSmall = 0xd744;
  static_assert(kMaxSmall * kMaxSmall * kMaxSmall * kMaxSmall <= kint64max,
                "bad overflow check");
  bool large_size = false;
  for (auto s : dim_sizes) {
    if (s > kMaxSmall) {
      large_size = true;
      break;
    }
  }

  if (!large_size) {
    // Every size fits in 16 bits; use fast-paths for dims in {1,2,3,4}.
    uint16* dst = as16()->dims_;
    switch (dim_sizes.size()) {
      case 1: {
        set_ndims_byte(1);
        const int64 size = dim_sizes[0];
        const bool neg = Set16(kIsPartial, dst, 0, size);
        set_num_elements(neg ? -1 : size);
        return;
      }
      case 2: {
        set_ndims_byte(2);
        const int64 size0 = dim_sizes[0];
        const int64 size1 = dim_sizes[1];
        bool neg = Set16(kIsPartial, dst, 0, size0);
        neg |= Set16(kIsPartial, dst, 1, size1);
        set_num_elements(neg ? -1 : (size0 * size1));
        return;
      }
      case 3: {
      ...
      }
      case 4: {
      ...
      }
    }
  }

  set_ndims_byte(0);
  set_num_elements(1);
  for (int64 s : dim_sizes) {
    AddDim(internal::SubtleMustCopy(s));
  }
}

缩减(内联)快速路径的体积可降低代码规模和指令缓存压力，从而提升性能。

parse_context.h

template <typename T>
PROTOBUF_NODISCARD const char* VarintParse(const char* p, T* out) {
  auto ptr = reinterpret_cast<const uint8_t*>(p);
  uint32_t res = ptr[0];
  if (!(res & 0x80)) {
    *out = res;
    return p + 1;
  }
  uint32_t byte = ptr[1];
  res += (byte - 1) << 7;
  if (!(byte & 0x80)) {
    *out = res;
    return p + 2;
  }
  return VarintParseSlow(p, res, out);
}

template <typename T>
PROTOBUF_NODISCARD const char* VarintParse(const char* p, T* out) {
  auto ptr = reinterpret_cast<const uint8_t*>(p);
  uint32_t res = ptr[0];
  if (!(res & 0x80)) {
    *out = res;
    return p + 1;
  }
  return VarintParseSlow(p, res, out);
}

parse_context.cc

std::pair<const char*, uint32_t> VarintParseSlow32(const char* p,
                                                   uint32_t res) {
  for (std::uint32_t i = 2; i < 5; i++) {
  ...
}
...
std::pair<const char*, uint64_t> VarintParseSlow64(const char* p,
                                                   uint32_t res32) {
  uint64_t res = res32;
  for (std::uint32_t i = 2; i < 10; i++) {
  ...
}

std::pair<const char*, uint32_t> VarintParseSlow32(const char* p,
                                                   uint32_t res) {
  for (std::uint32_t i = 1; i < 5; i++) {
  ...
}
...
std::pair<const char*, uint64_t> VarintParseSlow64(const char* p,
                                                   uint32_t res32) {
  uint64_t res = res32;
  for (std::uint32_t i = 1; i < 10; i++) {
  ...
}

rpc-stats.h

struct RPC_Stats_Measurement {
  ...
  double errors[RPC::NUM_ERRORS];

struct RPC_Stats_Measurement {
  ...
  double get_errors(int index) const { return errors[index]; }
  void set_errors(int index, double value) {
    errors[index] = value;
    any_errors_set = true;
  }
 private:
  ...
  // We make this private so that we can keep track of whether any of
  // these values have been set to non-zero values.
  double errors[RPC::NUM_ERRORS];
  bool any_errors_set;  // True iff any of the errors[i] values are non-zero

rpc-stats.cc

void RPC_Stats_Measurement::operator+=(const RPC_Stats_Measurement& x) {
  ...
  for (int i = 0; i < RPC::NUM_ERRORS; ++i) {
    errors[i] += x.errors[i];
  }
}

void RPC_Stats_Measurement::operator+=(const RPC_Stats_Measurement& x) {
  ...
  if (x.any_errors_set) {
    for (int i = 0; i < RPC::NUM_ERRORS; ++i) {
      errors[i] += x.errors[i];
    }
    any_errors_set = true;
  }
}

soft-tokens-helper.cc

bool SoftTokensHelper::IsSoftToken(const StringPiece& token) const {
  return soft_tokens_.find(Fingerprint(token.data(), token.size())) !=
      soft_tokens_.end();
}

soft-tokens-helper.h

class SoftTokensHelper {
 ...
 private:
  ...
  // Since soft tokens are mostly punctuation-related, for performance
  // purposes, we keep an array filter_.  filter_[i] is true iff any
  // of the soft tokens start with the byte value 'i'.  This avoids
  // fingerprinting a term in the common case, since we can just do an array
  // lookup based on the first byte, and if filter_[b] is false, then
  // we can return false immediately.
  bool          filter_[256];
  ...
};

inline bool SoftTokensHelper::IsSoftToken(const StringPiece& token) const {
  if (token.size() >= 1) {
    char first_char = token.data()[0];
    if (!filter_[first_char]) {
      return false;
    }
  }
  return IsSoftTokenFallback(token);
}

soft-tokens-helper.cc

bool SoftTokensHelper::IsSoftTokenFallback(const StringPiece& token) const {
  return soft_tokens_.find(Fingerprint(token.data(), token.size())) !=
      soft_tokens_.end();
}

executor.cc

struct NodeItem {
  ...
  bool kernel_is_expensive = false;  // True iff kernel->IsExpensive()
  bool kernel_is_async = false;      // True iff kernel->AsAsync() != nullptr
  bool is_merge = false;             // True iff IsMerge(node)
  ...
  if (IsEnter(node)) {
  ...
  } else if (IsExit(node)) {
  ...
  } else if (IsNextIteration(node)) {
  ...
  } else {
    // Normal path for most nodes
    ...
  }

struct NodeItem {
  ...
  bool kernel_is_expensive : 1;  // True iff kernel->IsExpensive()
  bool kernel_is_async : 1;      // True iff kernel->AsAsync() != nullptr
  bool is_merge : 1;             // True iff IsMerge(node)
  bool is_enter : 1;             // True iff IsEnter(node)
  bool is_exit : 1;              // True iff IsExit(node)
  bool is_control_trigger : 1;   // True iff IsControlTrigger(node)
  bool is_sink : 1;              // True iff IsSink(node)
  // True iff IsEnter(node) || IsExit(node) || IsNextIteration(node)
  bool is_enter_exit_or_next_iter : 1;
  ...
  if (!item->is_enter_exit_or_next_iter) {
    // Fast path for nodes types that don't need special handling
    DCHECK_EQ(input_frame, output_frame);
    ...
  } else if (item->is_enter) {
  ...
  } else if (item->is_exit) {
  ...
  } else {
    DCHECK(IsNextIteration(node));
    ...
  }

byte_trigram_classifier.cc

void ByteTrigramClassifier::VerifyModel(void) const {
  ProbT class_sums[num_classes_];
  for (int cls = 0; cls < num_classes_; cls++) {
    class_sums[cls] = 0;
  }
  for (ByteNgramId id = 0; id < trigrams_.num_trigrams(); id++) {
    for (int cls = 0; cls < num_classes_; ++cls) {
      class_sums[cls] += Prob(trigram_probs_[id].log_probs[cls]);
    }
  }
  ...
}

void ByteTrigramClassifier::VerifyModel(void) const {
  CHECK_EQ(sizeof(ByteLogProbT), 1);
  ProbT fast_prob[256];
  for (int b = 0; b < 256; b++) {
    fast_prob[b] = Prob(static_cast<ByteLogProbT>(b));
  }

  ProbT class_sums[num_classes_];
  for (int cls = 0; cls < num_classes_; cls++) {
    class_sums[cls] = 0;
  }
  for (ByteNgramId id = 0; id < trigrams_.num_trigrams(); id++) {
    for (int cls = 0; cls < num_classes_; ++cls) {
      class_sums[cls] += fast_prob[trigram_probs_[id].log_probs[cls]];
    }
  }
  ...
}

literal_linearizer.cc

for (int64 i = 0; i < src_shape.dimensions(dimension_numbers.front());
     ++i) {

int64 dim_front = src_shape.dimensions(dimension_numbers.front());
const uint8* src_buffer_data = src_buffer.data();
uint8* dst_buffer_data = dst_buffer.data();
for (int64 i = 0; i < dim_front; ++i) {

sharding_propagation.cc

HloSharding alternative_sub_sharding =
    user.sharding().GetSubSharding(user.shape(), {i});
if (user.operand(i) == &instruction &&
    hlo_sharding_util::IsShardingMoreSpecific(alternative_sub_sharding,
                                              sub_sharding)) {
  sub_sharding = alternative_sub_sharding;
}

if (user.operand(i) == &instruction) {
  // Only evaluate GetSubSharding if this operand is of interest,
  // as it is relatively expensive.
  HloSharding alternative_sub_sharding =
      user.sharding().GetSubSharding(user.shape(), {i});
  if (hlo_sharding_util::IsShardingMoreSpecific(
          alternative_sub_sharding, sub_sharding)) {
    sub_sharding = alternative_sub_sharding;
  }
}

在高频的内存分配/释放调用中不更新统计数据。改为在低频调用的Stats()方法被调用时按需计算统计数据。

此项简单变更使Web服务器CPU使用率降低7.5%。

querytree.h

static const int kInitParseTreeSize = 200;   // initial size of querynode pool

static const int kInitParseTreeSize = 10;   // initial size of querynode pool

旧版搜索系统(约2000年)采用双层索引架构：一层存储全文索引，另一层仅存储标题和锚文本索引。我们曾优先搜索较小的标题/锚文本层。但出乎意料的是，优先搜索更大的全文索引层反而更经济——若全文层检索完毕，即可完全跳过标题/锚文本层(作为全文层的子集)。这种情况发生频率较高，使我们得以减少处理单次查询的平均磁盘寻道次数。

背景信息详见《大规模超文本网络搜索引擎解剖》中关于标题与锚文本处理的讨论。

该代码因在监控系统收集服务器统计数据时被调用而具有性能敏感性。

histogram_export.cc

void Histogram::PopulateBuckets(const string &prefix,
                                expvar::MapProto *const var) const {
                                ...
  for (int i = min_bucket; i <= max_bucket; ++i) {
    const double count = BucketCount(i);
    if (!export_empty_buckets && count == 0.0) continue;
    acc += count;
    // The label format of exported buckets for discrete histograms
    // specifies an inclusive upper bound, which is the same as in
    // the original Histogram implementation.  This format is not
    // applicable to non-discrete histograms, so a half-open interval
    // is used for them, with "_" instead of "-" as a separator to
    // make possible to distinguish the formats.
    string key =
        options_.export_cumulative_counts() ?
            StringPrintf("%.12g", boundaries_->BucketLimit(i)) :
        options_.discrete() ?
            StringPrintf("%.0f-%.0f",
                         ceil(boundaries_->BucketStart(i)),
                         ceil(boundaries_->BucketLimit(i)) - 1.0) :
            StringPrintf("%.12g_%.12g",
                         boundaries_->BucketStart(i),
                         boundaries_->BucketLimit(i));
    EscapeMapKey(&key);
    const double value = options_.export_cumulative_counts() ? acc : count;
    expvar::AddMapFloat(StrCat(prefix,
                               options_.export_bucket_key_prefix(),
                               key),
                        value * count_mult,
                        var);
  }

// Format "val" according to format.  If "need_escape" is true, then the
// format can produce output with a '.' in it, and the result will be escaped.
// If "need_escape" is false, then the caller guarantees that format is
// such that the resulting number will not have any '.' characters and
// therefore we can avoid calling EscapeKey.
// The function is free to use "*scratch" for scratch space if necessary,
// and the resulting StringPiece may point into "*scratch".
static StringPiece FormatNumber(const char* format,
                                bool need_escape,
                                double val, string* scratch) {
  // This routine is specialized to work with only a limited number of formats
  DCHECK(StringPiece(format) == "%.0f" || StringPiece(format) == "%.12g");

  scratch->clear();
  if (val == trunc(val) && val >= kint32min && val <= kint32max) {
    // An integer for which we can just use StrAppend
    StrAppend(scratch, static_cast<int32>(val));
    return StringPiece(*scratch);
  } else if (isinf(val)) {
    // Infinity, represent as just 'inf'.
    return StringPiece("inf", 3);
  } else {
    // Format according to "format", and possibly escape.
    StringAppendF(scratch, format, val);
    if (need_escape) {
      EscapeMapKey(scratch);
    } else {
      DCHECK(!StringPiece(*scratch).contains("."));
    }
    return StringPiece(*scratch);
  }
}
...
void Histogram::PopulateBuckets(const string &prefix,
                                expvar::MapProto *const var) const {
                                ...
  const string full_key_prefix = StrCat(prefix,
                                        options_.export_bucket_key_prefix());
  string key = full_key_prefix;  // Keys will start with "full_key_prefix".
  string start_scratch;
  string limit_scratch;
  const bool cumul_counts = options_.export_cumulative_counts();
  const bool discrete = options_.discrete();
  for (int i = min_bucket; i <= max_bucket; ++i) {
    const double count = BucketCount(i);
    if (!export_empty_buckets && count == 0.0) continue;
    acc += count;
    // The label format of exported buckets for discrete histograms
    // specifies an inclusive upper bound, which is the same as in
    // the original Histogram implementation.  This format is not
    // applicable to non-discrete histograms, so a half-open interval
    // is used for them, with "_" instead of "-" as a separator to
    // make possible to distinguish the formats.
    key.resize(full_key_prefix.size());  // Start with full_key_prefix.
    DCHECK_EQ(key, full_key_prefix);

    const double limit = boundaries_->BucketLimit(i);
    if (cumul_counts) {
      StrAppend(&key, FormatNumber("%.12g", true, limit, &limit_scratch));
    } else {
      const double start = boundaries_->BucketStart(i);
      if (discrete) {
        StrAppend(&key,
                  FormatNumber("%.0f", false, ceil(start), &start_scratch),
                  "-",
                  FormatNumber("%.0f", false, ceil(limit) - 1.0,
                               &limit_scratch));
      } else {
        StrAppend(&key,
                  FormatNumber("%.12g", true, start, &start_scratch),
                  "_",
                  FormatNumber("%.12g", true, limit, &limit_scratch));
      }
    }
    const double value = cumul_counts ? acc : count;

    // Add to map var
    expvar::AddMapFloat(key, value * count_mult, var);
  }
}

VLOG是代码库中频繁使用的宏。此变更避免在几乎所有调用点额外传递整数常量(当调用点日志级别固定时，如VLOG(1) << ...)，从而节省代码空间。

vlog_is_on.h

class VLogSite final {
 public:
  ...
  bool IsEnabled(int level) {
    int stale_v = v_.load(std::memory_order_relaxed);
    if (ABSL_PREDICT_TRUE(level > stale_v)) {
      return false;
    }

    // We put everything other than the fast path, i.e. vlogging is initialized
    // but not on, behind an out-of-line function to reduce code size.
    return SlowIsEnabled(stale_v, level);
  }
  ...
 private:
  ...
  ABSL_ATTRIBUTE_NOINLINE
  bool SlowIsEnabled(int stale_v, int level);
  ...
};

class VLogSite final {
 public:
  ...
  bool IsEnabled(int level) {
    int stale_v = v_.load(std::memory_order_relaxed);
    if (ABSL_PREDICT_TRUE(level > stale_v)) {
      return false;
    }

    // We put everything other than the fast path, i.e. vlogging is initialized
    // but not on, behind an out-of-line function to reduce code size.
    // "level" is almost always a call-site constant, so we can save a bit
    // of code space by special-casing for levels 1, 2, and 3.
#if defined(__has_builtin) && __has_builtin(__builtin_constant_p)
    if (__builtin_constant_p(level)) {
      if (level == 0) return SlowIsEnabled0(stale_v);
      if (level == 1) return SlowIsEnabled1(stale_v);
      if (level == 2) return SlowIsEnabled2(stale_v);
      if (level == 3) return SlowIsEnabled3(stale_v);
      if (level == 4) return SlowIsEnabled4(stale_v);
      if (level == 5) return SlowIsEnabled5(stale_v);
    }
#endif
    return SlowIsEnabled(stale_v, level);
    ...
 private:
  ...
  ABSL_ATTRIBUTE_NOINLINE
  bool SlowIsEnabled(int stale_v, int level);
  ABSL_ATTRIBUTE_NOINLINE bool SlowIsEnabled0(int stale_v);
  ABSL_ATTRIBUTE_NOINLINE bool SlowIsEnabled1(int stale_v);
  ABSL_ATTRIBUTE_NOINLINE bool SlowIsEnabled2(int stale_v);
  ABSL_ATTRIBUTE_NOINLINE bool SlowIsEnabled3(int stale_v);
  ABSL_ATTRIBUTE_NOINLINE bool SlowIsEnabled4(int stale_v);
  ABSL_ATTRIBUTE_NOINLINE bool SlowIsEnabled5(int stale_v);
  ...
};

vlog_is_on.cc

bool VLogSite::SlowIsEnabled0(int stale_v) { return SlowIsEnabled(stale_v, 0); }
bool VLogSite::SlowIsEnabled1(int stale_v) { return SlowIsEnabled(stale_v, 1); }
bool VLogSite::SlowIsEnabled2(int stale_v) { return SlowIsEnabled(stale_v, 2); }
bool VLogSite::SlowIsEnabled3(int stale_v) { return SlowIsEnabled(stale_v, 3); }
bool VLogSite::SlowIsEnabled4(int stale_v) { return SlowIsEnabled(stale_v, 4); }
bool VLogSite::SlowIsEnabled5(int stale_v) { return SlowIsEnabled(stale_v, 5); }

read_matcher.cc

enum MatchItemType {
  MATCH_TYPE_INVALID,
  MATCH_TYPE_RANGE,
  MATCH_TYPE_EXACT,
  MATCH_TYPE_REGEXP,
};

enum MatchItemType {
  MATCH_TYPE_INVALID,
  MATCH_TYPE_RANGE,
  MATCH_TYPE_EXACT,
  MATCH_TYPE_REGEXP,
  MATCH_TYPE_PREFIX,   // Special type for regexp ".*"
};

read_matcher.cc

p->type = MATCH_TYPE_REGEXP;

term.NonMetaPrefix().CopyToString(&p->prefix);
if (term.RegexpSuffix() == ".*") {
  // Special case for a regexp that matches anything, so we can
  // bypass RE2::FullMatch
  p->type = MATCH_TYPE_PREFIX;
} else {
  p->type = MATCH_TYPE_REGEXP;

ipaddress.cc

string IPAddress::ToString() const {
  char buf[INET6_ADDRSTRLEN];

  switch (address_family_) {
    case AF_INET:
      CHECK(inet_ntop(AF_INET, &addr_.addr4, buf, INET6_ADDRSTRLEN) != NULL);
      return buf;
    case AF_INET6:
      CHECK(inet_ntop(AF_INET6, &addr_.addr6, buf, INET6_ADDRSTRLEN) != NULL);
      return buf;
    case AF_UNSPEC:
      LOG(DFATAL) << "Calling ToString() on an empty IPAddress";
      return "";
    default:
      LOG(FATAL) << "Unknown address family " << address_family_;
  }
}
...
string IPAddressToURIString(const IPAddress& ip) {
  switch (ip.address_family()) {
    case AF_INET6:
      return StringPrintf("[%s]", ip.ToString().c_str());
    default:
      return ip.ToString();
  }
}
...
string SocketAddress::ToString() const {
  return IPAddressToURIString(host_) + StringPrintf(":%u", port_);
}

string IPAddress::ToString() const {
  char buf[INET6_ADDRSTRLEN];

  switch (address_family_) {
    case AF_INET: {
      uint32 addr = gntohl(addr_.addr4.s_addr);
      int a1 = static_cast<int>((addr >> 24) & 0xff);
      int a2 = static_cast<int>((addr >> 16) & 0xff);
      int a3 = static_cast<int>((addr >> 8) & 0xff);
      int a4 = static_cast<int>(addr & 0xff);
      return StrCat(a1, ".", a2, ".", a3, ".", a4);
    }
    case AF_INET6:
      CHECK(inet_ntop(AF_INET6, &addr_.addr6, buf, INET6_ADDRSTRLEN) != NULL);
      return buf;
    case AF_UNSPEC:
      LOG(DFATAL) << "Calling ToString() on an empty IPAddress";
      return "";
    default:
      LOG(FATAL) << "Unknown address family " << address_family_;
  }
}
...
string IPAddressToURIString(const IPAddress& ip) {
  switch (ip.address_family()) {
    case AF_INET6:
      return StrCat("[", ip.ToString(), "]");
    default:
      return ip.ToString();
  }
}
...
string SocketAddress::ToString() const {
  return StrCat(IPAddressToURIString(host_), ":", port_);
}

dp_ops.cc

InputOutputMappingProto mapping_proto;
PLAQUE_OP_REQUIRES(
    mapping_proto.ParseFromStringPiece(GetAttrMappingProto(state)),
    absl::InternalError("Failed to parse InputOutputMappingProto"));
ParseMapping(mapping_proto);

uint64 mapping_proto_fp = GetAttrMappingProtoFp(state);
{
  absl::MutexLock l(&fp_to_iometa_mu);
  if (fp_to_iometa == nullptr) {
    fp_to_iometa =
        new absl::flat_hash_map<uint64, std::unique_ptr<ProgramIOMetadata>>;
  }
  auto it = fp_to_iometa->find(mapping_proto_fp);
  if (it != fp_to_iometa->end()) {
    io_metadata_ = it->second.get();
  } else {
    auto serial_proto = GetAttrMappingProto(state);
    DCHECK_EQ(mapping_proto_fp, Fingerprint(serial_proto));
    InputOutputMappingProto mapping_proto;
    PLAQUE_OP_REQUIRES(
        mapping_proto.ParseFromStringPiece(GetAttrMappingProto(state)),
        absl::InternalError("Failed to parse InputOutputMappingProto"));
    auto io_meta = ParseMapping(mapping_proto);
    io_metadata_ = io_meta.get();
    (*fp_to_iometa)[mapping_proto_fp] = std::move(io_meta);
  }
}

shape_util.h

struct ForEachState {
  ForEachState(const Shape& s, absl::Span<const int64_t> b,
               absl::Span<const int64_t> c, absl::Span<const int64_t> i);
  ~ForEachState();

  const Shape& shape;
  const absl::Span<const int64_t> base;
  const absl::Span<const int64_t> count;
  const absl::Span<const int64_t> incr;

struct ForEachState {
  ForEachState(const Shape& s, absl::Span<const int64_t> b,
               absl::Span<const int64_t> c, absl::Span<const int64_t> i);
  inline ~ForEachState() = default;

  const Shape& shape;
  // Pointers to arrays of the passed-in spans
  const int64_t* const base;
  const int64_t* const count;
  const int64_t* const incr;

crc.cc

void CRC32::Extend(uint64 *lo, uint64 *hi, const void *bytes, size_t length)
                      const {
                      ...
  // Process bytes 4 at a time
  while ((p + 4) <= e) {
    uint32 c = l ^ WORD(p);
    p += 4;
    l = this->table3_[c & 0xff] ^
        this->table2_[(c >> 8) & 0xff] ^
        this->table1_[(c >> 16) & 0xff] ^
        this->table0_[c >> 24];
  }

  // Process the last few bytes
  while (p != e) {
    int c = (l & 0xff) ^ *p++;
    l = this->table0_[c] ^ (l >> 8);
  }
  *lo = l;
}

void CRC32::Extend(uint64 *lo, uint64 *hi, const void *bytes, size_t length)
                      const {
                      ...
#define STEP {                                  \
    uint32 c = l ^ WORD(p);                     \
    p += 4;                                     \
    l = this->table3_[c & 0xff] ^               \
        this->table2_[(c >> 8) & 0xff] ^        \
        this->table1_[(c >> 16) & 0xff] ^       \
        this->table0_[c >> 24];                 \
}

  // Process bytes 16 at a time
  while ((e-p) >= 16) {
    STEP;
    STEP;
    STEP;
    STEP;
  }

  // Process bytes 4 at a time
  while ((p + 4) <= e) {
    STEP;
  }
#undef STEP

  // Process the last few bytes
  while (p != e) {
    int c = (l & 0xff) ^ *p++;
    l = this->table0_[c] ^ (l >> 8);
  }
  *lo = l;
}

1. 手动展开循环以每次处理四个字符，而非使用memchr
2. 手动展开循环以查找名称的分隔部分
3. 使用’#’分隔符时，反向查找名称分隔部分(而非正向)，因为名称首部分通常最长。

key.cc

void Key::InitSeps(const char* start) {
  const char* base = &rep_[0];
  const char* limit = base + rep_.size();
  const char* s = start;

  DCHECK_GE(s, base);
  DCHECK_LT(s, limit);

  for (int i = 0; i < 3; i++) {
    s = (const char*)memchr(s, '#', limit - s);
    DCHECK(s != NULL);
    seps_[i] = s - base;
    s++;
  }
}

inline const char* ScanBackwardsForSep(const char* base, const char* p) {
  while (p >= base + 4) {
    if (p[0] == '#') return p;
    if (p[-1] == '#') return p-1;
    if (p[-2] == '#') return p-2;
    if (p[-3] == '#') return p-3;
    p -= 4;
  }
  while (p >= base && *p != '#') p--;
  return p;
}

void Key::InitSeps(const char* start) {
  const char* base = &rep_[0];
  const char* limit = base + rep_.size();
  const char* s = start;

  DCHECK_GE(s, base);
  DCHECK_LT(s, limit);

  // We go backwards from the end of the string, rather than forwards,
  // since the directory name might be long and definitely doesn't contain
  // any '#' characters.
  const char* p = ScanBackwardsForSep(s, limit - 1);
  DCHECK(*p == '#');
  seps_[2] = p - base;
  p--;

  p = ScanBackwardsForSep(s, p);
  DCHECK(*p == '#');
  seps_[1] = p - base;
  p--;

  p = ScanBackwardsForSep(s, p);
  DCHECK(*p == '#');
  seps_[0] = p - base;
}

arena_cleanup.h

inline ABSL_ATTRIBUTE_ALWAYS_INLINE size_t Size(Tag tag) {
  if (!EnableSpecializedTags()) return sizeof(DynamicNode);

  switch (tag) {
    case Tag::kDynamic:
      return sizeof(DynamicNode);
    case Tag::kString:
      return sizeof(TaggedNode);
    case Tag::kCord:
      return sizeof(TaggedNode);
    default:
      ABSL_LOG(FATAL) << "Corrupted cleanup tag: " << static_cast<int>(tag);
      return sizeof(DynamicNode);
  }
}

inline ABSL_ATTRIBUTE_ALWAYS_INLINE size_t Size(Tag tag) {
  if (!EnableSpecializedTags()) return sizeof(DynamicNode);

  switch (tag) {
    case Tag::kDynamic:
      return sizeof(DynamicNode);
    case Tag::kString:
      return sizeof(TaggedNode);
    case Tag::kCord:
      return sizeof(TaggedNode);
    default:
      ABSL_DCHECK(false) << "Corrupted cleanup tag: " << static_cast<int>(tag);
      return sizeof(DynamicNode);
  }
}

该变更使设置警报的时间从771纳秒缩短至271纳秒。

selectserver.h

class SelectServer {
 public:
 ...
 protected:
  ...
  scoped_ptr<MinuteTenMinuteHourStat> num_alarms_stat_;
  ...
  scoped_ptr<MinuteTenMinuteHourStat> num_closures_stat_;
  ...
};

// Selectserver class
class SelectServer {
 ...
 protected:
 ...
};

/selectserver.cc

void SelectServer::AddAlarmInternal(Alarmer* alarmer,
                                    int offset_in_ms,
                                    int id,
                                    bool is_periodic) {
                                    ...
  alarms_->insert(alarm);
  num_alarms_stat_->IncBy(1);
  ...
}

void SelectServer::AddAlarmInternal(Alarmer* alarmer,
                                    int offset_in_ms,
                                    int id,
                                    bool is_periodic) {
                                    ...
  alarms_->Add(alarm);
  ...
}

/selectserver.cc

void SelectServer::RemoveAlarm(Alarmer* alarmer, int id) {
      ...
      alarms_->erase(alarm);
      num_alarms_stat_->IncBy(-1);
      ...
}

void SelectServer::RemoveAlarm(Alarmer* alarmer, int id) {
      ...
      alarms_->Remove(alarm);
      ...
}

采样机制使我们无需处理绝大多数请求的39个直方图及MinuteTenMinuteHour统计数据。

generic-leaf-stats.cc

... code that touches 39 histograms to update various stats on every request ...

// Add to the histograms periodically
if (TryLockToUpdateHistogramsDocInfo(docinfo_stats, bucket)) {
  // Returns true and grabs bucket->lock only if we should sample this
  // request for maintaining stats
  ... code that touches 39 histograms to update various stats ...
  bucket->lock.Unlock();
}

本次变更将采样率从1/10降至1/32。此外，我们仅对采样事件保留执行时间统计数据，并通过采用二进制模数运算加速采样决策。该代码在Google Meet视频会议系统中对每个数据包执行，因用户在疫情初期快速转向线上会议，为满足容量需求而进行性能优化。

packet_executor.cc

class ScopedPerformanceMeasurement {
 public:
  explicit ScopedPerformanceMeasurement(PacketExecutor* packet_executor)
      : packet_executor_(packet_executor),
        tracer_(packet_executor->packet_executor_trace_threshold_,
                kClosureTraceName) {
    // ThreadCPUUsage is an expensive call. At the time of writing,
    // it takes over 400ns, or roughly 30 times slower than absl::Now,
    // so we sample only 10% of closures to keep the cost down.
    if (packet_executor->closures_executed_ % 10 == 0) {
      thread_cpu_usage_start_ = base::ThreadCPUUsage();
    }

    // Sample start time after potentially making the above expensive call,
    // so as not to pollute wall time measurements.
    run_start_time_ = absl::Now();
  }

  ~ScopedPerformanceMeasurement() {

ScopedPerformanceMeasurement::ScopedPerformanceMeasurement(
    PacketExecutor* packet_executor)
    : packet_executor_(packet_executor),
      tracer_(packet_executor->packet_executor_trace_threshold_,
              kClosureTraceName) {
  // ThreadCPUUsage is an expensive call. At the time of writing,
  // it takes over 400ns, or roughly 30 times slower than absl::Now,
  // so we sample only 1 in 32 closures to keep the cost down.
  if (packet_executor->closures_executed_ % 32 == 0) {
    thread_cpu_usage_start_ = base::ThreadCPUUsage();
  }

  // Sample start time after potentially making the above expensive call,
  // so as not to pollute wall time measurements.
  run_start_time_ = absl::Now();
}

packet_executor.cc

~ScopedPerformanceMeasurement() {
  auto run_end_time = absl::Now();
  auto run_duration = run_end_time - run_start_time_;

  if (thread_cpu_usage_start_.has_value()) {
  ...
  }

  closure_execution_time->Record(absl::ToInt64Microseconds(run_duration));

ScopedPerformanceMeasurement::~ScopedPerformanceMeasurement() {
  auto run_end_time = absl::Now();
  auto run_duration = run_end_time - run_start_time_;

  if (thread_cpu_usage_start_.has_value()) {
    ...
    closure_execution_time->Record(absl::ToInt64Microseconds(run_duration));
  }

基准测试结果：

Run on (40 X 2793 MHz CPUs); 2020-03-24T20:08:19.991412535-07:00
CPU: Intel Ivybridge with HyperThreading (20 cores) dL1:32KB dL2:256KB dL3:25MB
Benchmark                                      Base (ns)    New (ns) Improvement
----------------------------------------------------------------------------
BM_PacketOverhead_mean                               224          85    +62.0%

此为大规模变更中的局部调整。

gpu_bfc_allocator.cc

void GPUBFCAllocator::SplitChunk(...) {
  ...
  VLOG(6) << "Adding to chunk map: " << new_chunk->ptr;
  ...
}
...
void GPUBFCAllocator::DeallocateRawInternal(void* ptr) {
  ...
  VLOG(6) << "Chunk at " << c->ptr << " no longer in use";
  ...
}

void GPUBFCAllocator::SplitChunk(...) {
...
}
...
void GPUBFCAllocator::DeallocateRawInternal(void* ptr) {
...
}

image_similarity.cc

for (int j = 0; j < output_subimage_size_y; j++) {
  int j1 = j - rad + output_to_integral_subimage_y;
  int j2 = j1 + 2 * rad + 1;
  // Create a pointer for this row's output, taking into account the offset
  // to the full image.
  double *image_diff_ptr = &(*image_diff)(j + min_j, min_i);

  for (int i = 0; i < output_subimage_size_x; i++) {
    ...
    if (VLOG_IS_ON(3)) {
    ...
    }
    ...
  }
}

const bool vlog_3 = DEBUG_MODE ? VLOG_IS_ON(3) : false;

for (int j = 0; j < output_subimage_size_y; j++) {
  int j1 = j - rad + output_to_integral_subimage_y;
  int j2 = j1 + 2 * rad + 1;
  // Create a pointer for this row's output, taking into account the offset
  // to the full image.
  double *image_diff_ptr = &(*image_diff)(j + min_j, min_i);

  for (int i = 0; i < output_subimage_size_x; i++) {
    ...
    if (vlog_3) {
    ...
    }
  }
}

Run on (40 X 2801 MHz CPUs); 2016-05-16T15:55:32.250633072-07:00
CPU: Intel Ivybridge with HyperThreading (20 cores) dL1:32KB dL2:256KB dL3:25MB
Benchmark                          Base (ns)  New (ns) Improvement
------------------------------------------------------------------
BM_NCCPerformance/16                   29104     26372     +9.4%
BM_NCCPerformance/64                  473235    425281    +10.1%
BM_NCCPerformance/512               30246238  27622009     +8.7%
BM_NCCPerformance/1k              125651445  113361991     +9.8%
BM_NCCLimitedBoundsPerformance/16       8314      7498     +9.8%
BM_NCCLimitedBoundsPerformance/64     143508    132202     +7.9%
BM_NCCLimitedBoundsPerformance/512   9335684   8477567     +9.2%
BM_NCCLimitedBoundsPerformance/1k   37223897  34201739     +8.1%

periodic_call.cc

  VLOG(1) << Logid()
          << "MaybeScheduleAlarmAtNextTick. Time until next real time: "
          << time_until_next_real_time;
          ...
  uint64 next_virtual_time_ms =
      next_virtual_time_ms_ - num_ticks * kResolutionMs;
  CHECK_GE(next_virtual_time_ms, 0);
  ScheduleAlarm(now, delay, next_virtual_time_ms);
}

void ScheduleNextAlarm(uint64 current_virtual_time_ms)
    ABSL_EXCLUSIVE_LOCKS_REQUIRED(mutex_) {
  if (calls_.empty()) {
    VLOG(1) << Logid() << "No calls left, entering idle mode";
    next_real_time_ = absl::InfiniteFuture();
    return;
  }
  uint64 next_virtual_time_ms = FindNextVirtualTime(current_virtual_time_ms);
  auto delay =
      absl::Milliseconds(next_virtual_time_ms - current_virtual_time_ms);
  ScheduleAlarm(GetClock().TimeNow(), delay, next_virtual_time_ms);
}

// An alarm scheduled by this function supersedes all previously scheduled
// alarms. This is ensured through `scheduling_sequence_number_`.
void ScheduleAlarm(absl::Time now, absl::Duration delay,
                   uint64 virtual_time_ms)
    ABSL_EXCLUSIVE_LOCKS_REQUIRED(mutex_) {
  next_real_time_ = now + delay;
  next_virtual_time_ms_ = virtual_time_ms;
  ++ref_count_;  // The Alarm holds a reference.
  ++scheduling_sequence_number_;
  VLOG(1) << Logid() << "ScheduleAlarm. Time : "
          << absl::FormatTime("%M:%S.%E3f", now, absl::UTCTimeZone())
          << ", delay: " << delay << ", virtual time: " << virtual_time_ms
          << ", refs: " << ref_count_
          << ", seq: " << scheduling_sequence_number_
          << ", executor: " << executor_;

  executor_->AddAfter(
      delay, new Alarm(this, virtual_time_ms, scheduling_sequence_number_));
}

  const bool vlog_1 = VLOG_IS_ON(1);

  if (vlog_1) {
    VLOG(1) << Logid()
            << "MaybeScheduleAlarmAtNextTick. Time until next real time: "
            << time_until_next_real_time;
  }
  ...
  uint64 next_virtual_time_ms =
      next_virtual_time_ms_ - num_ticks * kResolutionMs;
  CHECK_GE(next_virtual_time_ms, 0);
  ScheduleAlarm(now, delay, next_virtual_time_ms, vlog_1);
}

void ScheduleNextAlarm(uint64 current_virtual_time_ms, bool vlog_1)
    ABSL_EXCLUSIVE_LOCKS_REQUIRED(mutex_) {
  if (calls_.empty()) {
    if (vlog_1) {
      VLOG(1) << Logid() << "No calls left, entering idle mode";
    }
    next_real_time_ = absl::InfiniteFuture();
    return;
  }
  uint64 next_virtual_time_ms = FindNextVirtualTime(current_virtual_time_ms);
  auto delay =
      absl::Milliseconds(next_virtual_time_ms - current_virtual_time_ms);
  ScheduleAlarm(GetClock().TimeNow(), delay, next_virtual_time_ms, vlog_1);
}

// An alarm scheduled by this function supersedes all previously scheduled
// alarms. This is ensured through `scheduling_sequence_number_`.
void ScheduleAlarm(absl::Time now, absl::Duration delay,
                   uint64 virtual_time_ms,
                   bool vlog_1)
    ABSL_EXCLUSIVE_LOCKS_REQUIRED(mutex_) {
  next_real_time_ = now + delay;
  next_virtual_time_ms_ = virtual_time_ms;
  ++ref_count_;  // The Alarm holds a reference.
  ++scheduling_sequence_number_;
  if (vlog_1) {
    VLOG(1) << Logid() << "ScheduleAlarm. Time : "
            << absl::FormatTime("%M:%S.%E3f", now, absl::UTCTimeZone())
            << ", delay: " << delay << ", virtual time: " << virtual_time_ms
            << ", refs: " << ref_count_
            << ", seq: " << scheduling_sequence_number_
            << ", executor: " << executor_;
  }

  executor_->AddAfter(
      delay, new Alarm(this, virtual_time_ms, scheduling_sequence_number_));
}

避免创建 Ok 对象，通过将致命错误消息的复杂格式化操作移出调用点实现，从而节省代码空间。

status.h

#define TF_CHECK_OK(val) CHECK_EQ(::tensorflow::Status::OK(), (val))
#define TF_QCHECK_OK(val) QCHECK_EQ(::tensorflow::Status::OK(), (val))

extern tensorflow::string* TfCheckOpHelperOutOfLine(
    const ::tensorflow::Status& v, const char* msg);
inline tensorflow::string* TfCheckOpHelper(::tensorflow::Status v,
                                           const char* msg) {
  if (v.ok()) return nullptr;
  return TfCheckOpHelperOutOfLine(v, msg);
}
#define TF_CHECK_OK(val)                                           \
  while (tensorflow::string* _result = TfCheckOpHelper(val, #val)) \
  LOG(FATAL) << *(_result)
#define TF_QCHECK_OK(val)                                          \
  while (tensorflow::string* _result = TfCheckOpHelper(val, #val)) \
  LOG(QFATAL) << *(_result)

status.cc

string* TfCheckOpHelperOutOfLine(const ::tensorflow::Status& v,
                                 const char* msg) {
  string r("Non-OK-status: ");
  r += msg;
  r += " status: ";
  r += v.ToString();
  // Leaks string but this is only to be used in a fatal error message
  return new string(r);
}

1. 新增专用于 RETURN_IF_ERROR 的特殊适配器类。
2. 在 RETURN_IF_ERROR 的快速路径中不再构造/销毁 StatusBuilder。
3. 因快速路径不再需要，不再内联部分 StatusBuilder 方法。
4. 避免不必要的 ~Status 调用。

logging.h

struct CheckOpString {
  CheckOpString(string* str) : str_(str) { }
  ~CheckOpString() { delete str_; }
  operator bool() const { return str_ == NULL; }
  string* str_;
};
...
#define DEFINE_CHECK_OP_IMPL(name, op) \
  template <class t1, class t2> \
  inline string* Check##name##Impl(const t1& v1, const t2& v2, \
                                   const char* names) { \
    if (v1 op v2) return NULL; \
    else return MakeCheckOpString(v1, v2, names); \
  } \
  string* Check##name##Impl(int v1, int v2, const char* names);
DEFINE_CHECK_OP_IMPL(EQ, ==)
DEFINE_CHECK_OP_IMPL(NE, !=)
DEFINE_CHECK_OP_IMPL(LE, <=)
DEFINE_CHECK_OP_IMPL(LT, < )
DEFINE_CHECK_OP_IMPL(GE, >=)
DEFINE_CHECK_OP_IMPL(GT, > )
#undef DEFINE_CHECK_OP_IMPL

struct CheckOpString {
  CheckOpString(string* str) : str_(str) { }
  // No destructor: if str_ is non-NULL, we're about to LOG(FATAL),
  // so there's no point in cleaning up str_.
  operator bool() const { return str_ == NULL; }
  string* str_;
};
...
extern string* MakeCheckOpStringIntInt(int v1, int v2, const char* names);

template<int, int>
string* MakeCheckOpString(const int& v1, const int& v2, const char* names) {
  return MakeCheckOpStringIntInt(v1, v2, names);
}
...
#define DEFINE_CHECK_OP_IMPL(name, op) \
  template <class t1, class t2> \
  inline string* Check##name##Impl(const t1& v1, const t2& v2, \
                                   const char* names) { \
    if (v1 op v2) return NULL; \
    else return MakeCheckOpString(v1, v2, names); \
  } \
  inline string* Check##name##Impl(int v1, int v2, const char* names) { \
    if (v1 op v2) return NULL; \
    else return MakeCheckOpString(v1, v2, names); \
  }
DEFINE_CHECK_OP_IMPL(EQ, ==)
DEFINE_CHECK_OP_IMPL(NE, !=)
DEFINE_CHECK_OP_IMPL(LE, <=)
DEFINE_CHECK_OP_IMPL(LT, < )
DEFINE_CHECK_OP_IMPL(GE, >=)
DEFINE_CHECK_OP_IMPL(GT, > )
#undef DEFINE_CHECK_OP_IMPL

logging.cc

string* MakeCheckOpStringIntInt(int v1, int v2, const char* names) {
  strstream ss;
  ss << names << " (" << v1 << " vs. " << v2 << ")";
  return new string(ss.str(), ss.pcount());
}

该变更停止对许多非性能敏感函数(如错误路径和操作符注册代码)进行内联处理。此外，部分性能敏感函数的慢速路径被移至非内联函数中。

这些变更使典型二进制文件中的TensorFlow符号体积缩减12.2%(从8814545字节降至7740233字节)。

协议缓冲区库变更。避免为≥128字节的消息编码消息长度时消耗昂贵的内联代码空间，转而调用共享的非内联例程。

不仅能缩小重要大型二进制文件的体积，还能提升运行速度。

某大型二进制文件中高度内联例程每行生成的代码字节数。首列数字代表特定源代码行生成的总字节数，包含所有内联位置。

变更前：

.           0   1825 template <typename MessageType>
.           0   1826 inline uint8* WireFormatLite::InternalWriteMessage(
.           0   1827     int field_number, const MessageType& value, uint8* target,
.           0   1828     io::EpsCopyOutputStream* stream) {
>>>    389246   1829   target = WriteTagToArray(field_number, WIRETYPE_LENGTH_DELIMITED, target);
>>>   5454640   1830   target = io::CodedOutputStream::WriteVarint32ToArray(
>>>    337837   1831       static_cast<uint32>(value.GetCachedSize()), target);
>>>   1285539   1832   return value._InternalSerialize(target, stream);
.           0   1833 }

变更后代码大小输出如下：

.           0   1825 template <typename MessageType>
.           0   1826 inline uint8* WireFormatLite::InternalWriteMessage(
.           0   1827     int field_number, const MessageType& value, uint8* target,
.           0   1828     io::EpsCopyOutputStream* stream) {
>>>    450612   1829   target = WriteTagToArray(field_number, WIRETYPE_LENGTH_DELIMITED, target);
>>       9609   1830   target = io::CodedOutputStream::WriteVarint32ToArrayOutOfLine(
>>>    434668   1831       static_cast<uint32>(value.GetCachedSize()), target);
>>>   1597394   1832   return value._InternalSerialize(target, stream);
.           0   1833 }

coded_stream.h

class PROTOBUF_EXPORT CodedOutputStream {
  ...
  // Like WriteVarint32()  but writing directly to the target array, and with the
  // less common-case paths being out of line rather than inlined.
  static uint8* WriteVarint32ToArrayOutOfLine(uint32 value, uint8* target);
  ...
};
...
inline uint8* CodedOutputStream::WriteVarint32ToArrayOutOfLine(uint32 value,
                                                               uint8* target) {
  target[0] = static_cast<uint8>(value);
  if (value < 0x80) {
    return target + 1;
  } else {
    return WriteVarint32ToArrayOutOfLineHelper(value, target);
  }
}

coded_stream.cc

uint8* CodedOutputStream::WriteVarint32ToArrayOutOfLineHelper(uint32 value,
                                                              uint8* target) {
  DCHECK_GE(value, 0x80);
  target[0] |= static_cast<uint8>(0x80);
  value >>= 7;
  target[1] = static_cast<uint8>(value);
  if (value < 0x80) {
    return target + 2;
  }
  target += 2;
  do {
    // Turn on continuation bit in the byte we just wrote.
    target[-1] |= static_cast<uint8>(0x80);
    value >>= 7;
    *target = static_cast<uint8>(value);
    ++target;
  } while (value >= 0x80);
  return target;
}

1. 将不依赖特定哈希表类型的代码提取为通用(非内联)函数。
2. 审慎放置 ABSL_ATTRIBUTE_NOINLINE 指令。
3. 将部分低效路径移出内联处理。

使部分大型二进制文件体积缩减约 0.5%。

public/arenastring.h

  if (IsDefault(default_value)) {
    std::string* new_string = new std::string();
    tagged_ptr_.Set(new_string);
    return new_string;
  } else {
    return UnsafeMutablePointer();
  }
}

  if (IsDefault(default_value)) {
    return SetAndReturnNewString();
  } else {
    return UnsafeMutablePointer();
  }
}

internal/arenastring.cc

std::string* ArenaStringPtr::SetAndReturnNewString() {
  std::string* new_string = new std::string();
  tagged_ptr_.Set(new_string);
  return new_string;
}

op.h

class OpDefBuilderWrapper {
 public:
  explicit OpDefBuilderWrapper(const char name[]) : builder_(name) {}
  OpDefBuilderWrapper& Attr(std::string spec) {
    builder_.Attr(std::move(spec));
    return *this;
  }
  OpDefBuilderWrapper& Input(std::string spec) {
    builder_.Input(std::move(spec));
    return *this;
  }
  OpDefBuilderWrapper& Output(std::string spec) {
    builder_.Output(std::move(spec));
    return *this;
  }

class OpDefBuilderWrapper {
 public:
  explicit OpDefBuilderWrapper(const char name[]) : builder_(name) {}
  OpDefBuilderWrapper& Attr(std::string spec) {
    builder_.Attr(std::move(spec));
    return *this;
  }
  OpDefBuilderWrapper& Attr(const char* spec) TF_ATTRIBUTE_NOINLINE {
    return Attr(std::string(spec));
  }
  OpDefBuilderWrapper& Input(std::string spec) {
    builder_.Input(std::move(spec));
    return *this;
  }
  OpDefBuilderWrapper& Input(const char* spec) TF_ATTRIBUTE_NOINLINE {
    return Input(std::string(spec));
  }
  OpDefBuilderWrapper& Output(std::string spec) {
    builder_.Output(std::move(spec));
    return *this;
  }
  OpDefBuilderWrapper& Output(const char* spec) TF_ATTRIBUTE_NOINLINE {
    return Output(std::string(spec));
  }

将一个基于布尔值的大型模板化例程改为将布尔值作为额外参数传递。(该布尔值仅用于选择两个字符串常量之一，因此运行时检查完全可行。)此举将大型例程的实例化次数从287次减少至143次。

sharding_util_ops.cc

template <bool Split>
Status GetAndValidateAttributes(OpKernelConstruction* ctx,
                                std::vector<int32>& num_partitions,
                                int& num_slices, std::vector<int32>& paddings,
                                bool& has_paddings) {
  absl::string_view num_partitions_attr_name =
      Split ? kNumSplitsAttrName : kNumConcatsAttrName;
      ...
  return OkStatus();
}

Status GetAndValidateAttributes(bool split, OpKernelConstruction* ctx,
                                std::vector<int32>& num_partitions,
                                int& num_slices, std::vector<int32>& paddings,
                                bool& has_paddings) {
  absl::string_view num_partitions_attr_name =
      split ? kNumSplitsAttrName : kNumConcatsAttrName;
      ...
  return OkStatus();
}

同时将模板实例化次数从每种<T, Device, Rank>组合各一次，优化为每种<T>和每种<Rank>各一次。

sharding_util_ops.cc

template <typename Device, typename T>
class XlaSplitNDBaseOp : public OpKernel {
 public:
  explicit XlaSplitNDBaseOp(OpKernelConstruction* ctx) : OpKernel(ctx) {
    OP_REQUIRES_OK(
        ctx, GetAndValidateAttributes(/*split=*/true, ctx, num_splits_,
                                      num_slices_, paddings_, has_paddings_));
  }

// Shared base class to save code space
class XlaSplitNDShared : public OpKernel {
 public:
  explicit XlaSplitNDShared(OpKernelConstruction* ctx) TF_ATTRIBUTE_NOINLINE
      : OpKernel(ctx),
        num_slices_(1),
        has_paddings_(false) {
    GetAndValidateAttributes(/*split=*/true, ctx, num_splits_, num_slices_,
                             paddings_, has_paddings_);
  }

• 将不依赖特定哈希表类型的代码提取为通用(非内联)函数。
• 审慎放置 ABSL_ATTRIBUTE_NOINLINE 指令。
• 将部分低效路径移出行内实现。

textfallback_init.h

inline void AddEmojiFallbacks(TextFallbackMap *map) {
  (*map)[0xFE000] = &kFE000;
  (*map)[0xFE001] = &kFE001;
  (*map)[0xFE002] = &kFE002;
  (*map)[0xFE003] = &kFE003;
  (*map)[0xFE004] = &kFE004;
  (*map)[0xFE005] = &kFE005;
  ...
  (*map)[0xFEE7D] = &kFEE7D;
  (*map)[0xFEEA0] = &kFEEA0;
  (*map)[0xFE331] = &kFE331;
};

inline void AddEmojiFallbacks(TextFallbackMap *map) {
#define PAIR(x) {0x##x, &k##x}
  // clang-format off
  map->insert({
    PAIR(FE000),
    PAIR(FE001),
    PAIR(FE002),
    PAIR(FE003),
    PAIR(FE004),
    PAIR(FE005),
    ...
    PAIR(FEE7D),
    PAIR(FEEA0),
    PAIR(FE331)});
  // clang-format on
#undef PAIR
};

将原被内联的超长例程从.h文件移至.cc文件(内联此处并无实际性能收益)。

reduction_ops_common.h

Status Simplify(const Tensor& data, const Tensor& axis,
                const bool keep_dims) {
  ... Eighty line routine body ...
}

Status Simplify(const Tensor& data, const Tensor& axis, const bool keep_dims);

blocked-token-coder.cc

MutexLock l(&encoder_threads_lock);
if (encoder_threads == NULL) {
  encoder_threads = new ThreadPool(NumCPUs());
  encoder_threads->SetStackSize(262144);
  encoder_threads->StartWorkers();
}
encoder_threads->Add
    (NewCallback(this,
                 &BlockedTokenEncoder::EncodeRegionInThread,
                 region_tokens, N, region,
                 stats,
                 controller_->GetClosureWithCost
                 (NewCallback(&DummyCallback), N)));

coding.cc

for (int c = 0; c < clusters->size(); c++) {
  RET_CHECK_OK(DecodeBulkForCluster(...);
}

struct SubTask {
  absl::Status result;
  absl::Notification done;
};

std::vector<SubTask> tasks(clusters->size());
for (int c = 0; c < clusters->size(); c++) {
  options_.executor->Schedule([&, c] {
    tasks[c].result = DecodeBulkForCluster(...);
    tasks[c].done.Notify();
  });
}
for (int c = 0; c < clusters->size(); c++) {
  tasks[c].done.WaitForNotification();
}
for (int c = 0; c < clusters->size(); c++) {
  RETURN_IF_ERROR(tasks[c].result);
}

mustang-query.cc

// Pool of query nodes
ThreadSafeFreeList<MustangQuery> pool_(256);
...
void MustangQuery::Release(MustangQuery* node) {
  if (node == NULL)
    return;
  for (int i=0; i < node->children_->size(); ++i)
    Release((*node->children_)[i]);
  node->children_->clear();
  pool_.Delete(node);
}

// Pool of query nodes
Mutex pool_lock_;
FreeList<MustangQuery> pool_(256);
...
void MustangQuery::Release(MustangQuery* node) {
  if (node == NULL)
    return;
  MutexLock l(&pool_lock_);
  ReleaseLocked(node);
}

void MustangQuery::ReleaseLocked(MustangQuery* node) {
#ifndef NDEBUG
  pool_lock_.AssertHeld();
#endif
  if (node == NULL)
    return;
  for (int i=0; i < node->children_->size(); ++i)
    ReleaseLocked((*node->children_)[i]);
  node->children_->clear();
  pool_.Delete(node);
}

通过精心调整数据结构，显著降低了访问的缓存行数量，使机器学习训练性能提升3.3%。

1. 预先计算节点项数据结构中的某些节点类型属性，将其存储为位值，从而在关键区内处理出边时无需访问Node*对象。
2. 将ExecutorState::ActivateNodes修改为使用目标节点的NodeItem，而非访问*item->node对象的字段。通常这意味着访问所需边数据仅需触及1至2条缓存行，而非原先的~2 + O(出边数量)(对于多核处理的大型图，此举还可减轻TLB压力)。

trainer.cc

{
  // Notify the parameter server that we are starting.
  MutexLock l(&lock_);
  model_ = model;
  MaybeRecordProgress(last_global_step_);
}

bool should_start_record_progress = false;
int64 step_for_progress = -1;
{
  // Notify the parameter server that we are starting.
  MutexLock l(&lock_);
  model_ = model;
  should_start_record_progress = ShouldStartRecordProgress();
  step_for_progress = last_global_step_;
}
if (should_start_record_progress) {
  StartRecordProgress(step_for_progress);
}

cache.cc

class ShardedLRUCache : public Cache {
 private:
  LRUCache shard_[kNumShards];
  port::Mutex id_mutex_;
  uint64_t last_id_;

  static inline uint32_t HashSlice(const Slice& s) {
    return Hash(s.data(), s.size(), 0);
  }

  static uint32_t Shard(uint32_t hash) {
    return hash >> (32 - kNumShardBits);
  }
  ...
  virtual Handle* Lookup(const Slice& key) {
    const uint32_t hash = HashSlice(key);
    return shard_[Shard(hash)].Lookup(key, hash);
  }

transaction_manager.cc

absl::MutexLock l(&active_calls_in_mu_);
ActiveCallMap::const_iterator iter = active_calls_in_.find(m->tid());
if (iter != active_calls_in_.end()) {
  iter->second.ExtractElements(&m->tmp_calls_);
}

ActiveCalls::LockedShard shard(active_calls_in_, m->tid());
const ActiveCallMap& active_calls_map = shard.active_calls_map();
ActiveCallMap::const_iterator iter = active_calls_map.find(m->tid());
if (iter != active_calls_map.end()) {
  iter->second.ExtractElements(&m->tmp_calls_);
}

netmon_map_impl.h

ConnectionBucket* GetBucket(Index index) {
  // Rehash the hash to make sure we are not partitioning the buckets based on
  // the original hash. If num_buckets_ is a power of 2 that would drop the
  // entropy of the buckets.
  size_t original_hash = absl::Hash<Index>()(index);
  int hash = absl::Hash<size_t>()(original_hash) % num_buckets_;
  return &buckets_[hash];
}

ConnectionBucket* GetBucket(Index index) {
  absl::Hash<std::pair<Index, size_t>> hasher{};
  // Combine the hash with 42 to prevent shard selection using the same bits
  // as the underlying hashtable.
  return &buckets_[hasher({index, 42}) % num_buckets_];
}

此代码变更将 ActiveCallMap 分区为 64 个分片。每个分片由独立互斥锁保护。特定事务将映射至唯一分片。新增 LockedShard(tid) 接口，支持线程安全访问事务的 ActiveCallMap。使用示例：

transaction_manager.cc

{
  absl::MutexLock l(&active_calls_in_mu_);
  delayed_locks_timer_ring_.Add(delayed_locks_flush_time_ms, tid);
}

{
  ActiveCalls::LockedShard shard(active_calls_in_, tid);
  shard.delayed_locks_timer_ring().Add(delayed_locks_flush_time_ms, tid);
}

测试结果显示：在8192个纤维环境下运行基准测试时，整体墙钟时间缩短69%

Benchmark                   Time(ns)        CPU(ns)     Iterations
------------------------------------------------------------------
BM_ActiveCalls/8k        11854633492     98766564676            10
BM_ActiveCalls/16k       26356203552    217325836709            10

Benchmark                   Time(ns)        CPU(ns)     Iterations
------------------------------------------------------------------
BM_ActiveCalls/8k         3696794642     39670670110            10
BM_ActiveCalls/16k        7366284437     79435705713            10

histogram.h

HistogramOptions options_;
...
internal::HistogramBoundaries *boundaries_;
...
std::vector<double> buckets_;

double min_;             // Minimum.
double max_;             // Maximum.
double count_;           // Total count of occurrences.
double sum_;             // Sum of values.
double sum_of_squares_;  // Sum of squares of values.
...
RegisterVariableExporter *exporter_;

  HistogramOptions options_;
  ...
  internal::HistogramBoundaries *boundaries_;
  ...
  RegisterVariableExporter *exporter_;
  ...
  // Place the following fields in a dedicated cacheline as they are frequently
  // mutated, so we can avoid potential false sharing.
  ...
#ifndef SWIG
  alignas(ABSL_CACHELINE_SIZE)
#endif
  std::vector<double> buckets_;

  double min_;             // Minimum.
  double max_;             // Maximum.
  double count_;           // Total count of occurrences.
  double sum_;             // Sum of values.
  double sum_of_squares_;  // Sum of squares of values.

cast_op.cc

template <typename Device, typename Tout, typename Tin>
void CastMaybeInline(const Device& d, typename TTypes<Tout>::Flat o,
                     typename TTypes<Tin>::ConstFlat i) {
  if (o.size() * (sizeof(Tin) + sizeof(Tout)) < 16384) {
    // Small cast on a CPU: do inline
    o = i.template cast<Tout>();
  } else {
    o.device(d) = i.template cast<Tout>();
  }
}

RPC存根缓存条目每秒被读取数千次，修改频率极低。切换至合适的无锁映射可降低3%-5%的检索延迟。

dynamic_token_class_manager.h

mutable Mutex mutex_;

// The density of this hash map is guaranteed by the fact that the
// dynamic lexicon reuses previously allocated TokenIds before trying
// to allocate new ones.
dense_hash_map<TokenId, common::LocalTokenClassId> tid_to_cid_
    GUARDED_BY(mutex_);

// Read accesses to this hash-map should be done using
// 'epoch_gc_'::(EnterFast / LeaveFast). The writers should periodically
// GC the deleted entries, by simply invoking LockFreeHashMap::CreateGC.
typedef util::gtl::LockFreeHashMap<TokenId, common::LocalTokenClassId>
    TokenIdTokenClassIdMap;
TokenIdTokenClassIdMap tid_to_cid_;

name                old time/op  new time/op  delta
BenchmarkIteration  17.4µs ± 5%   0.8µs ± 1%  -95.30%  (p=0.000 n=11+12)

Protobuf版本：

message PointProto {
  int32 x = 1;
  int32 y = 2;
}
message PointListProto {
  repeated PointProto points = 1;
}

void SumProto(const PointListProto& vec) {
  int sum = 0;
  for (const PointProto& p : vec.points()) {
    sum += p.y();
  }
  ABSL_VLOG(1) << sum;
}

void BenchmarkIteration() {
  PointListProto points;
  points.mutable_points()->Reserve(1000);
  for (int i = 0; i < 1000; i++) {
    PointProto* p = points.add_points();
    p->set_x(i);
    p->set_y(i * 2);
  }
  SumProto(points);
}

非Protobuf版本：

struct PointStruct {
  int x;
  int y;
};

void SumVector(const std::vector<PointStruct>& vec) {
  int sum = 0;
  for (const PointStruct& p : vec) {
    sum += p.y;
  }
  ABSL_VLOG(1) << sum;
}

void BenchmarkIteration() {
  std::vector<PointStruct> points;
  points.reserve(1000);
  for (int i = 0; i < 1000; i++) {
    points.push_back({i, i * 2});
  }
  SumVector(points);
}

鉴于上述20倍的性能差异，若某些数据从未被序列化或解析，则不应将其封装在协议缓冲区中。协议缓冲区的核心价值在于简化数据结构的序列化与反序列化，但其可能带来显著的代码体积、内存及CPU开销。若仅需DebugString和可复制性等次要特性，则无需使用协议缓冲区。

消息层次结构有助于以更易读的方式组织信息。但额外的层次会带来内存分配、函数调用、缓存未命中、序列化消息增大等开销。

例如，请避免使用：

message Foo {
  optional Bar bar = 1;
}
message Bar {
  optional Baz baz = 1;
}
message Baz {
  optional int32 count = 1;
}

而应采用：

message Foo {
  optional int32 count = 1;
}

协议缓冲区消息在 C++ 生成的代码中对应消息类，传输时会发送标签及有效负载长度。旧格式传输整数时需要更多分配(和释放)操作，并生成更多代码。因此所有协议缓冲区操作(解析、序列化、大小计算等)都变得更耗时，需要遍历消息树。新形式不存在此类开销，效率更高。

Protobuf采用可变长整数表示字段编号与传输格式组合(详见编码规范文档)。字段编号1至15占用1字节，16至2047占用2字节。(通常应避免使用2048及以上的字段编号。)

建议为未来扩展性能敏感型Protobuf预留部分小字段编号。

通常使用int32或int64，但对于哈希码等大值应采用fixed32或fixed64，而经常出现负值的情况则应使用sint32或sint64。

变长整型编码小整数时占用更少字节，可节省空间但解码成本更高。但处理负值或大值时可能占用更多空间。此时使用fixed32或fixed64(而非uint32或uint64)可大幅降低编码解码成本并缩小体积。对于小型负整数，请使用sint32或sint64替代int32或int64。

在Proto2中，重复值默认以(标签, 值)对序列化。这种方式效率低下，因为每个元素都需要解码标签。

打包重复基本类型时，先序列化有效负载长度，随后跟随无标签的值。使用固定宽度值时，解析开始时即可知晓最终大小，从而避免重新分配内存；即无重新分配开销。但仍无法预知有效负载中包含多少变长整数，可能仍需承担重新分配成本。

在Proto3中，重复字段默认采用紧凑格式。

紧凑格式最适用于固定宽度值(如fixed32、fixed64、float、double等)，因其编码长度可通过元素数量乘以固定值大小预先确定，无需逐个计算单个元素长度。

string类型存储UTF8编码文本，有时需要进行验证。bytes类型可存储任意字节序列(非文本数据)，通常比string更合适且更高效。

解析过程中复制大型字符串或字节字段会消耗大量资源。通常可通过为字段标记 string_type = VIEW 来规避此成本。

message Image {
  ...
  bytes jpeg_encoding = 4 [features.(pb.cpp).string_type=VIEW];
}

若未添加VIEW注解，解析协议缓冲区时，潜在的大型字段内容将从序列化协议缓冲区复制到内存中的字符串对象。根据字符串或字节字段的数量及大小，复制开销可能相当显著。

替代复制二进制大块数据，诸如ParseFromStringWithAliasing等例程会使用absl::string_view引用原始底层字符串。需注意底层字符串(序列化协议缓冲区)的生命周期必须长于包含别名的协议缓冲区实例。

为大型bytes和string字段添加[ctype=CORD]注解可降低复制成本。该注解将字段表示形式从std::string转换为absl::Cord。absl::Cord采用引用计数和树形存储结构，有效减少复制与追加操作的开销。若协议缓冲区序列化为Cord格式，解析带[ctype=CORD]注释的字符串/字节字段时可避免复制字段内容。

message Document {
  ...
  bytes html = 4 [ctype = CORD];
}

Cord字段的性能取决于长度分布和访问模式。请通过基准测试验证此类变更效果。

建议使用区域机制节省分配与释放开销，尤其适用于包含重复字符串或消息字段的协议缓冲区。

消息字段和字符串字段采用堆分配(即使顶级协议缓冲区对象为栈分配)。若协议缓冲区消息包含大量子消息字段和字符串字段，分配与释放开销可能显著增加。内存池可摊销分配成本，使释放操作几乎零开销，同时通过从连续内存块分配资源来提升内存局部性。

避免在单个.proto文件中放置过多消息。一旦依赖该文件的任何内容，即使大部分内容未被使用，链接器仍会加载整个文件，导致构建时间延长和二进制文件增大。可通过扩展和Any类型避免对包含大量消息类型的庞大.proto文件产生硬性依赖。

内存中的协议缓冲区对象占用大量内存(通常是传输格式大小的5倍)，且可能分散在多个缓存行中。因此，若应用程序需长期保持大量协议缓冲区对象处于活动状态，请考虑采用序列化形式存储。

Protobuf映射字段存在性能问题，其弊端通常远大于语法上的微小便利性。建议使用非Protobuf映射结构，并从Protobuf内容初始化：

msg.proto

map<string, bytes> env_variables = 5;

message Var {
  string key = 1;
  bytes value = 2;
}
repeated Var env_variables = 5;

若需访问大型消息类型的少量字段，可考虑定义自定义协议缓冲区消息类型：复刻原始类型结构，仅定义所需字段。示例如下：

message FullMessage {
  optional int32 field1 = 1;
  optional BigMessage field2 = 2;
  optional int32 field3 = 3;
  repeater AnotherBigMessage field4 = 4;
  ...
  optional int32 field100 = 100;
}

message SubsetMessage {
  optional int32 field3 = 3;
  optional int32 field88 = 88;
}

将序列化的FullMessage解析为SubsetMessage时，仅解析百分之一百字段中的两个，其余视为未知字段。在合适场景下，建议使用舍弃未知字段的API以进一步提升性能。

在循环外部声明 protobuf 对象，使其分配的存储空间可在循环迭代中复用。

languages.cc

class CodeToLanguage
    ...
    : public __gnu_cxx::hash_map<absl::string_view, i18n::languages::Language,
                                 CodeHash, CodeCompare> {

class CodeToLanguage
    ...
    : public absl::flat_hash_map<absl::string_view, i18n::languages::Language,
                                 CodeHash, CodeCompare> {

基准测试结果：

name               old time/op  new time/op  delta
BM_CodeToLanguage  19.4ns ± 1%  10.2ns ± 3%  -47.47%  (p=0.000 n=8+10)

publish.cc

typedef hash_map<uint64, Publication*> PublicationMap;
static PublicationMap* publications = NULL;

typedef dense_hash_map<uint64, Publication*> PublicationMap;;
static PublicationMap* publications GUARDED_BY(mu) = NULL;

alarmer.h

typedef hash_map<int, Alarm*> AlarmList;

typedef dense_hash_map<int, Alarm*> AlarmList;

register_allocator.h

using container_type = std::set<WorklistItem>;

using container_type = absl::btree_set<WorklistItem>;

block_encoder.cc

vector<bool> live_reads(nreads);
...
for (int offset = 0; offset < b_.block_width(); offset++) {
  ...
  for (int r = 0; r < nreads; r++) {
    if (live_reads[r]) {

util::bitmap::InlinedBitVector<4096> live_reads(nreads);
...
for (int offset = 0; offset < b_.block_width(); offset++) {
  ...
  for (size_t r = 0; live_reads.FindNextSetBit(&r); r++) {
    DCHECK(live_reads[r]);

bundle.h

class Bundle {
 public:
 ...
 private:
  // Sequence of (slotted instruction, unslotted immediate operands).
  std::vector<InstructionRecord> instructions_;
  ...
};

class Bundle {
 public:
 ...
 private:
  // Sequence of (slotted instruction, unslotted immediate operands).
  absl::InlinedVector<InstructionRecord, 2> instructions_;
  ...
};

table_ply.h

class TablePly {
    ...
    // Returns the set of data columns stored in this file for this table.
    const std::vector<FamilyId>& modified_data_columns() const {
      return modified_data_columns_;
    }
    ...
   private:
    ...
    std::vector<FamilyId> modified_data_columns_;  // Data columns in the table.

#include "util/gtl/vector32.h"
    ...
    // Returns the set of data columns stored in this file for this table.
    absl::Span<const FamilyId> modified_data_columns() const {
      return modified_data_columns_;
    }
    ...

    ...
    // Data columns in the table.
    gtl::vector32<FamilyId> modified_data_columns_;

tflite_model.cc

using ChoiceIdToContextMap = gtl::flat_hash_map<int, TFLiteContext*>;

using ChoiceIdToContextMap =
    gtl::small_map<gtl::flat_hash_map<int, TFLiteContext*>>;

broadcast_stream.h

class BroadcastStream : public ParsedRtpTransport {
 ...
 private:
  ...
  std::set<ParsedRtpTransport*> listeners_ ABSL_GUARDED_BY(listeners_mutex_);
};

class BroadcastStream : public ParsedRtpTransport {
 ...
 private:
  ...
  using ListenersSet =
      gtl::small_ordered_set<std::set<ParsedRtpTransport*>, 10>;
  ListenersSet listeners_ ABSL_GUARDED_BY(listeners_mutex_);

row-update-sender-inflight-set.h

std::set<int64> inflight_requests_ GUARDED_BY(mu_);

class SeqNum : public gtl::intrusive_link<SeqNum> {
  ...
  int64 val_ = -1;
  ...
};
...
gtl::intrusive_list<SeqNum> inflight_requests_ GUARDED_BY(mu_);

best_fit_allocator.cc

absl::StatusOr<int64> BestFitAllocator::RoundUpToAlignment(int64 bytes) const {
  TPU_RET_CHECK_GE(bytes, 0);

  const int64 max_aligned = MathUtil::RoundDownTo<int64>(
      std::numeric_limits<int64>::max(), alignment_in_bytes_);
  if (bytes > max_aligned) {
    return util::ResourceExhaustedErrorBuilder(ABSL_LOC)
           << "Attempted to allocate "
           << strings::HumanReadableNumBytes::ToString(bytes)
           << " which after aligning to "
           << strings::HumanReadableNumBytes::ToString(alignment_in_bytes_)
           << " cannot be expressed as an int64.";
  }

  return MathUtil::RoundUpTo<int64>(bytes, alignment_in_bytes_);
}

best_fit_allocator.h

// Rounds bytes up to nearest multiple of alignment_.
// REQUIRES: bytes >= 0.
// REQUIRES: result does not overflow int64.
// REQUIRES: alignment_in_bytes_ is a power of 2 (checked in constructor).
int64 RoundUpToAlignment(int64 bytes) const {
  DCHECK_GE(bytes, 0);
  DCHECK_LE(bytes, max_aligned_bytes_);
  int64 result =
      ((bytes + (alignment_in_bytes_ - 1)) & ~(alignment_in_bytes_ - 1));
  DCHECK_EQ(result, MathUtil::RoundUpTo<int64>(bytes, alignment_in_bytes_));
  return result;
}

shape_util.h

using ForEachVisitorFunction =
    absl::FunctionRef<StatusOr<bool>(absl::Span<const int64_t>)>;
    ...
static void ForEachIndex(const Shape& shape, absl::Span<const int64_t> base,
                         absl::Span<const int64_t> count,
                         absl::Span<const int64_t> incr,
                         const ForEachVisitorFunction& visitor_function);

using ForEachVisitorFunctionNoStatus =
    absl::FunctionRef<bool(absl::Span<const int64_t>)>;
    ...
static void ForEachIndexNoStatus(
    const Shape& shape, absl::Span<const int64_t> base,
    absl::Span<const int64_t> count, absl::Span<const int64_t> incr,
    const ForEachVisitorFunctionNoStatus& visitor_function);

literal.cc

ShapeUtil::ForEachIndex(
    result_shape, [&](absl::Span<const int64_t> output_index) {
      for (int64_t i = 0, end = dimensions.size(); i < end; ++i) {
        scratch_source_index[i] = output_index[dimensions[i]];
      }
      int64_t dest_index = IndexUtil::MultidimensionalIndexToLinearIndex(
          result_shape, output_index);
      int64_t source_index = IndexUtil::MultidimensionalIndexToLinearIndex(
          shape(), scratch_source_index);
      memcpy(dest_data + primitive_size * dest_index,
             source_data + primitive_size * source_index, primitive_size);
      return true;
    });

ShapeUtil::ForEachIndexNoStatus(
    result_shape, [&](absl::Span<const int64_t> output_index) {
      // Compute dest_index
      int64_t dest_index = IndexUtil::MultidimensionalIndexToLinearIndex(
          result_shape, result_minor_to_major, output_index);

      // Compute source_index
      int64_t source_index;
      for (int64_t i = 0, end = dimensions.size(); i < end; ++i) {
        scratch_source_array[i] = output_index[dimensions[i]];
      }
      if (src_shape_dims == 1) {
        // Fast path for this case
        source_index = scratch_source_array[0];
        DCHECK_EQ(source_index,
                  IndexUtil::MultidimensionalIndexToLinearIndex(
                      src_shape, src_minor_to_major, scratch_source_span));
      } else {
        source_index = IndexUtil::MultidimensionalIndexToLinearIndex(
            src_shape, src_minor_to_major, scratch_source_span);
      }
      // Move one element from source_index in source to dest_index in dest
      memcpy(dest_data + PRIMITIVE_SIZE * dest_index,
             source_data + PRIMITIVE_SIZE * source_index, PRIMITIVE_SIZE);
      return true;
    });

status.h

#define TF_CHECK_OK(val) CHECK_EQ(::tensorflow::Status::OK(), (val))
#define TF_QCHECK_OK(val) QCHECK_EQ(::tensorflow::Status::OK(), (val))

extern tensorflow::string* TfCheckOpHelperOutOfLine(
    const ::tensorflow::Status& v, const char* msg);
inline tensorflow::string* TfCheckOpHelper(::tensorflow::Status v,
                                           const char* msg) {
  if (v.ok()) return nullptr;
  return TfCheckOpHelperOutOfLine(v, msg);
}
#define TF_CHECK_OK(val)                                           \
  while (tensorflow::string* _result = TfCheckOpHelper(val, #val)) \
  LOG(FATAL) << *(_result)
#define TF_QCHECK_OK(val)                                          \
  while (tensorflow::string* _result = TfCheckOpHelper(val, #val)) \
  LOG(QFATAL) << *(_result)

移除热点路径中的StatusOr消除了先前变更导致的RPC基准测试中14%的CPU退化。

privacy_context.h

absl::StatusOr<privacy::context::PrivacyContext> GetRawPrivacyContext(
    const CensusHandle& h);

privacy_context_statusfree.h

enum class Result {
  kSuccess,
  kNoRootScopedData,
  kNoPrivacyContext,
  kNoDDTContext,
  kDeclassified,
  kNoPrequestContext
};
...
Result GetRawPrivacyContext(const CensusHandle& h,
                            PrivacyContext* privacy_context);

参见瑞士表设计笔记及相关CppCon 2017和 CppCon 2019 演讲。

raw_hash_set.h

// Returns a bitmask representing the positions of slots that match hash.
BitMask<uint32_t> Match(h2_t hash) const {
  auto ctrl = _mm_loadu_si128(reinterpret_cast<const __m128i*>(pos));
  auto match = _mm_set1_epi8(hash);
  return BitMask<uint32_t>(_mm_movemask_epi8(_mm_cmpeq_epi8(match, ctrl)));
}

ordered-code.cc

int len = 0;
while (val > 0) {
  len++;
  buf[9 - len] = (val & 0xff);
  val >>= 8;
}
buf[9 - len - 1] = (unsigned char)len;
len++;
FastStringAppend(dest, reinterpret_cast<const char*>(buf + 9 - len), len);

BigEndian::Store(val, buf + 1);  // buf[0] may be needed for length
const unsigned int length = OrderedNumLength(val);
char* start = buf + 9 - length - 1;
*start = length;
AppendUpto9(dest, start, length + 1);

Run on (12 X 3501 MHz CPUs); 2016-09-27T16:04:55.065995192-04:00
CPU: Intel Haswell with HyperThreading (6 cores) dL1:32KB dL2:256KB dL3:15MB
Benchmark                          Base (ns)  New (ns) Improvement
------------------------------------------------------------------
BM_OneOutput/3/2                      466867    351818    +24.6%
BM_OneOutput/4/2                      563130    474756    +15.7%
BM_OneOutput/5/3                      815393    688820    +15.5%
BM_OneOutput/6/3                      897246    780539    +13.0%
BM_OneOutput/8/4                     1270489   1137149    +10.5%
BM_AllOutputs/3/2                     848772    642942    +24.3%
BM_AllOutputs/4/2                    1067647    638139    +40.2%
BM_AllOutputs/5/3                    1739135   1151369    +33.8%
BM_AllOutputs/6/3                    2045817   1456744    +28.8%
BM_AllOutputs/8/4                    3012958   2484937    +17.5%
BM_AllOutputsSetUpOnce/3/2            717310    493371    +31.2%
BM_AllOutputsSetUpOnce/4/2            833866    600060    +28.0%
BM_AllOutputsSetUpOnce/5/3           1537870   1137357    +26.0%
BM_AllOutputsSetUpOnce/6/3           1802353   1398600    +22.4%
BM_AllOutputsSetUpOnce/8/4           3166930   2455973    +22.4%

引入GroupVarInt格式，该格式以5-17字节为单位批量编码/解码4个可变长整数组，而非逐个整数处理。采用新格式解码一组4个整数所需时间约为单独解码4个变长整数的1/3。

groupvarint.cc

const char* DecodeGroupVar(const char* p, int N, uint32* dest) {
  assert(groupvar_initialized);
  assert(N % 4 == 0);
  while (N) {
    uint8 tag = *p;
    p++;

    uint8* lenptr = &groupvar_table[tag].length[0];

#define GET_NEXT                                        \
    do {                                                \
      uint8 len = *lenptr;                              \
      *dest = UNALIGNED_LOAD32(p) & groupvar_mask[len]; \
      dest++;                                           \
      p += len;                                         \
      lenptr++;                                         \
    } while (0)
    GET_NEXT;
    GET_NEXT;
    GET_NEXT;
    GET_NEXT;
#undef GET_NEXT

    N -= 4;
  }
  return p;
}

新增KBitStreamEncoder和KBitStreamDecoder类，用于将4个k位数同时编码/解码为比特流。由于K值在编译时已知，编码与解码效率显著提升。例如：因每次编码4个数，代码可假设流始终按字节对齐(k为偶数时)或按半字节对齐(k为奇数时)。

GPU内存分配器加速约40%。

GPUBFCAllocator的分配/释放速度提升36-48%：

1. 通过句柄编号而非Chunk指针识别数据块。Chunk数据结构现分配于vector<Chunk>中，句柄作为该向量索引指向特定数据块。此举使Chunk对象的next/prev指针可采用ChunkHandle(4字节)替代Chunk*(8字节)。
2. 当Chunk对象不再使用时，维护自由列表：列表头由ChunkHandle free_chunks_list_标识，且Chunk->next指向下一个空闲列表项。结合方案(1)，这使分配器在绝大多数情况下(仅当vector<Chunk>扩展时)无需为Chunk对象进行堆分配/释放操作，同时确保所有Chunk对象内存连续。
3. 我们采用基于log₂(byte_size/256)函数索引的二进制数组替代std::set数据结构，通过该函数定位给定字节大小的二进制桶。此方案仅需少量位运算即可定位二进制桶，省去了二叉搜索树的查找开销。该方案还支持将所有Bin数据结构存储在连续数组中，而非分散于多个缓存行。当多线程同时进行分配时，这能减少跨核心移动的缓存行数量。
4. 为GPUBFCAllocator::AllocateRaw添加快速路径，优先尝试不调用retry_helper_的内存分配。若初始尝试失败(返回nullptr)，则转入retry_helper处理，但通常可避免多层过程调用及带多个参数的std::function分配/释放操作。
5. 注释掉大部分VLOG调用。调试时可通过取消注释并重新编译选择性启用。

新增多线程基准测试以检验竞争环境下的分配效率。

在搭载Titan X显卡的桌面机上，ptb_word_lm处理速度从每秒8036词提升至8272词(+2.9%)。

Run on (40 X 2801 MHz CPUs); 2016/02/16-15:12:49
CPU: Intel Ivybridge with HyperThreading (20 cores) dL1:32KB dL2:256KB dL3:25MB
Benchmark                          Base (ns)  New (ns) Improvement
------------------------------------------------------------------
BM_Allocation                            347       184    +47.0%
BM_AllocationThreaded/1                  351       181    +48.4%
BM_AllocationThreaded/4                 2470      1975    +20.0%
BM_AllocationThreaded/16               11846      9507    +19.7%
BM_AllocationDelayed/1                   392       199    +49.2%
BM_AllocationDelayed/10                  285       169    +40.7%
BM_AllocationDelayed/100                 245       149    +39.2%
BM_AllocationDelayed/1000                238       151    +36.6%

• 将多项特殊快速描述符解析函数统一整合至ParsedDescriptor类，并在更多场景使用该类以避免高成本的完整解析调用。
• 将若干协议缓冲字段从字符串类型改为字节类型(避免不必要的utf-8检查及相关错误处理代码)。
• DescriptorProto.inlined_contents 现为字符串类型而非 Cord 类型(仅适用于中等规模张量)。为此需在 tensor_util.cc 中添加多项复制辅助函数(现需同时支持字符串与 Cord 类型)。
• 在若干位置将 std::unordered_map 替换为 flat_hash_map。
• 为堆栈运算添加 MemoryManager::LookupMany 方法，替代按批次元素调用 Lookup 的方式。此变更可减少锁定等初始化开销。
• 移除 TransferDispatchOp 中部分冗余字符串创建操作。
• 在同一进程内传输 1000 个 1KB 张量批次的性能结果：

Before: 227.01 steps/sec
After:  272.52 steps/sec (+20% throughput)

为加速XLA编译所做的部分改动：

1. 在SortComputationsByContent中，若比较函数中a == b则返回false，避免对长计算字符串进行序列化和指纹识别。
2. 将 HloComputation::ComputeInstructionPostOrder 中的 CHECK 改为 DCHECK，避免额外触发缓存行访问。
3. 在 CoreSequencer::IsVectorSyncHoldSatisfied() 中避免对前导指令进行耗时的复制操作。
4. 重构HloComputation::ToString和HloComputation::ToCord双参数函数，将主要工作移至std::string拼接操作，而非Cord对象拼接。
5. 将PerformanceCounterSet::Increment的哈希表查找次数从两次改为一次。
6. 精简 Scoreboard::Update 代码

某重要模型在 XLA 编译阶段整体提速 14%。

优化 ScopedLogId 性能，该操作处于每个数据包的关键路径上。

• 移除了仅用于检测不变量是否被违反的 LOG_EVERY_N(ERROR, ...) 消息。
• 内联了 PushLogId 和 PopLogid() 例程(由于移除了 LOG_EVERY_N_SECONDS(ERROR, ...) 语句，这些例程现已足够小可进行内联)。
• 改用固定大小为4的数组及’int size’变量替代InlinedVector<...>来维护线程局部状态。由于实际使用中从未超过4个元素，InlinedVector的功能过于冗余。

Base: Baseline plus the code in scoped_logid_test.cc to add the benchmark
New: This changelist

CPU: Intel Ivybridge with HyperThreading (20 cores) dL1:32KB dL2:256KB dL3:25MB
Benchmark                                      Base (ns)    New (ns) Improvement
----------------------------------------------------------------------------
BM_ScopedLogId/threads:1                               8           4    +52.6%
BM_ScopedLogId/threads:2                               8           4    +51.9%
BM_ScopedLogId/threads:4                               8           4    +52.9%
BM_ScopedLogId/threads:8                               8           4    +52.1%
BM_ScopedLogId/threads:16                             11           6    +44.0%

多项提升XLA编译器性能的改动：

1. 从多方面提升ShapeUtil::ForEachIndex…迭代性能：
   • 在ShapeUtil::ForEachState中，仅保存指向数组的指针(而非完整span对象)。
   • 预先构造指向ShapeUtil::ForEachState::indexes向量的ShapeUtil::ForEachState::indexes_span，避免每次循环迭代时从向量构建该span。
   • 保存指向 ShapeUtil::ForEachState::indexes 向量后备存储的 ShapeUtil::ForEachState::indexes_ptr 指针，使 ShapeUtil::ForEachState::IncrementDim() 中可直接执行简单数组操作，而非更耗费资源的 vector::operator[] 操作。
   • 保存构造函数中通过调用 shape.layout().minor_to_major().data() 初始化的 ShapeUtil::ForEachState::minor_to_major 数组指针，避免每次迭代中为每个维度调用 LayoutUtil::Minor()。
   • 内联了 ShapeUtil::ForEachState 构造函数及 ShapeUtil::ForEachState::IncrementDim() 例程
2. 针对无需在传递函数中返回状态的调用场景，优化了 ShapeUtil::ForEachIndex 的迭代性能。通过引入ShapeUtil::ForEachIndexNoStatus变体实现，该变体接受返回简单bool值的ForEachVisitorFunctionNoStatus函数。相较于接受返回StatusOr<bool>的ForEachVisitorFunction(每次迭代元素都需要调用昂贵的StatusOr<bool>析构函数)，此方案更高效。
   • 在 LiteralBase::Broadcast 和 GenerateReduceOutputElement 中使用了 ShapeUtil::ForEachIndexNoStatus 的此变体。
3. 通过以下方式提升 LiteralBase::Broadcast 的性能：
   • 在 literal.cc 中引入模板化的 BroadcastHelper 例程，针对不同原始字节大小进行特化(未特化时，primitive_size 是运行时变量，导致编译器无法有效优化每个元素的 memcpy 操作，即使实际情况是微小的 2 的幂次方 (通常为1、2、4或8))。
   • 通过在LiteralBase::Broadcast例程开头仅调用一次’shape()’，将每次Broadcast调用中约(5 + num_dimensions + num_result_elements)次虚函数调用精简为仅一次。看似无害的’shape()’调用遍布各处，最终都可归结为“root_piece().subshape()”，其中subshape()是虚函数。
   • 在BroadcastHelper例程中，针对源维度为1的特殊情况，避免调用IndexUtil::MultiDimensionalIndexToLinearIndex函数。
   • 在 BroadcastHelper 中，使用了一个指向 scratch_source_index 向量后备存储区域的 scratch_source_array 指针变量，并直接使用该指针以避免在逐元素代码中进行 vector::operator[ ] 操作。同时在BroadcastHelper的逐元素循环外预先计算指向scratch_source_index向量的scratch_source_span，避免每次处理元素时都从向量构造span。
   • 在IndexUtil::MultiDimensionalIndexToLinearIndex中引入三参数变体，调用方需传入与shape参数关联的minor_to_major span。在BroadcastHelper中应用此变体，对src和dst形状进行全局广播计算(每次广播仅计算一次)，而非按元素复制次数重复计算。
4. 在ShardingPropagation::GetShardingFromUser中，针对HloOpcode::kTuple场景，仅当发现操作数具有处理价值时才调用user.sharding().GetSubSharding(…)。避免过早调用该方法使该例程的CPU时间从43.7秒缩短至2.0秒。
5. 新增ShapeUtil::ForEachIndex、Literal::Broadcast及新方法ShapeUtil::ForEachIndexNoStatus的基准测试。

Base is with the benchmark additions of
BM_ForEachIndex and BM_BroadcastVectorToMatrix (and BUILD file change to add
benchmark dependency), but no other changes.

New is this cl

Run on (72 X 1357.56 MHz CPU s) CPU Caches: L1 Data 32 KiB (x36)
L1 Instruction 32 KiB (x36) L2 Unified 1024 KiB (x36) L3 Unified 25344 KiB (x2)

Benchmark                                      Base (ns)    New (ns) Improvement
----------------------------------------------------------------------------
BM_MakeShape                                       18.40       18.90     -2.7%
BM_MakeValidatedShape                              35.80       35.60     +0.6%
BM_ForEachIndex/0                                  57.80       55.80     +3.5%
BM_ForEachIndex/1                                  90.90       85.50     +5.9%
BM_ForEachIndex/2                               1973606     1642197     +16.8%

新添加的ForEachIndexNoStatus比ForEachIndex变体快得多(它仅存在于此新cl中，但BM_ForEachIndexNoStatus/NUM完成的基准测试工作可与上述BM_ForEachIndex/NUM结果相媲美)。

Benchmark                                      Base (ns)    New (ns) Improvement
----------------------------------------------------------------------------
BM_ForEachIndexNoStatus/0                             0        46.90    ----
BM_ForEachIndexNoStatus/1                             0        65.60    ----
BM_ForEachIndexNoStatus/2                             0     1001277     ----

广播性能提升约58%。

Benchmark                                      Base (ns)    New (ns) Improvement
----------------------------------------------------------------------------
BM_BroadcastVectorToMatrix/16/16                   5556        2374     +57.3%
BM_BroadcastVectorToMatrix/16/1024               319510      131075     +59.0%
BM_BroadcastVectorToMatrix/1024/1024           20216949     8408188     +58.4%

大型语言模型预编译宏测试结果(程序不仅执行XLA编译，但XLA相关代码耗时占比不足一半)：

基准程序总耗时：573秒 采用此CL程序总耗时：465秒(提升19%)

运行该程序时两大XLA程序的编译耗时：

基准方案：141秒 + 143秒 = 284秒
采用此CL方案：99秒 + 95秒 = 194秒(提升31%)

通过微调实现约22%的编译加速：

1. 优化节点源代码共享检测效率。原方案需对各节点源代码排序后进行交集运算，现改为将单节点源代码放入哈希表，再遍历另一节点源代码进行哈希表查询。
2. 步骤1中复用同一临时哈希表。
3. 生成编译后proto时，采用单一pair<package, opname>键值的二叉树替代嵌套二叉树结构。
4. 将opdef指针存储于前置二叉树中，避免将opdef内容复制到二叉树内。

大型程序(约4.5万条操作)速度测试：

name             old time/op  new time/op  delta
BM_CompileLarge   28.5s ± 2%   22.4s ± 2%  -21.61%  (p=0.008 n=5+5)

MapReduce加速方案：

1. 修改了SafeCombinerMapOutput类的组合器数据结构。原先使用hash_multimap<SafeCombinerKey, StringPiece>(为表中每个唯一键值对创建哈希表条目)，现改用hash_map<SafeCombinerKey, ValuePtr*>(其中ValuePtr是包含值及其重复次数的链表)。此变更带来三重效益：
   • 显著降低内存占用：每个值仅需“sizeof(ValuePtr) + value_len”字节，而非原先“sizeof(SafeCombinerKey) + sizeof(StringPiece) + value_len + 新哈希表条目开销”。这意味着减少了清空reducer缓冲区的频率。
   • 显著提升速度，因为当为表中已存在键插入新值时，我们避免了额外的哈希表条目开销(只需将值挂接到该键的值链表中)。
   • 由于在链表中为每个值关联重复计数，我们可以将以下序列：

     Output(key, "1");
     Output(key, "1");
     Output(key, "1");
     Output(key, "1");
     Output(key, "1");

   作为“key”链表中重复计数为5的单条记录。内部会向用户级组合函数输出五次“1”。(此技巧或许也可应用于reduce侧)。

2. (次要)在默认的MapReductionBase::KeyFingerprintSharding函数中添加了“nshards == 1”的检测，当仅使用1个reduce分片时完全跳过键值指纹计算(此时可直接返回0而无需检查键值)。
3. 将组合器接收每个键值对时调用的代码路径中部分VLOG(3)语句改为DVLOG(3)。

单词计数基准测试耗时从12.56秒缩短至6.55秒。

重构SelectServer中的告警处理代码，显著提升其性能。

变更内容：

1. 将AlarmQueue的存储结构从set<Alarm*>切换为AdjustablePriorityQueue<Alarm>。此变更显著提升了警报处理速度，将添加/移除警报所需时间从771纳秒缩短至281纳秒。此变更避免了每次警报设置时对STL集合对象中红黑树节点的分配/释放操作，同时显著提升了缓存局部性(因AdjustablePriorityQueue采用向量实现堆结构而非红黑树)，在每次selectserver循环处理AlarmQueue时触发的缓存行数量大幅减少。
2. 将Alarmer中的AlarmList从hash_map转换为dense_hash_map，避免每次警报增删时额外分配/释放内存(此举同时提升了警报增删时的缓存局部性)。
3. 移除了num_alarms_stat_和num_closures_stat_这两个MinuteTenMinuteHourStat对象，以及对应的导出变量。虽然监控这些数据看似合理，但实际会给关键网络代码带来显著开销。若将这些变量保留为Atomic32类型而非MinuteTenMinuteHourStat，仍会使警报增删操作的成本从281纳秒增加至340纳秒。

基准测试结果

Benchmark                      Time(ns)  CPU(ns) Iterations
-----------------------------------------------------------
BM_AddAlarm/1                       902      771     777777

实施此变更后

Benchmark                      Time(ns)  CPU(ns) Iterations
-----------------------------------------------------------
BM_AddAlarm/1                       324      281    2239999

2001年规划从磁盘索引切换至内存索引服务时，我们发现了多个性能问题。本次变更解决了其中多数问题，使每秒内存查询量从150次提升至500次以上(基于双处理器奔腾III机器上2GB内存索引的测试)。

• 索引块解码速度大幅提升(微基准测试从8.9 MB/s提升至13.1 MB/s)。
• 解码过程中新增块校验和机制，使所有getsymbol操作无需边界检查即可完成。
• 采用粗糙的宏实现：将BitDecoder的各字段存储于局部变量中贯穿整个循环，并在循环末尾回写。
• 通过内联汇编调用Intel芯片的’bsf’指令实现getUnary(查找字中首个1位的索引)
• 将值解码至向量时，我们改为在循环外调整向量大小，仅沿向量移动指针，而非通过边界检查逐项存储值。
• 文档ID解码过程中，将文档ID保存在局部文档ID空间，避免乘以num_shards_。仅在需要实际文档ID值时才进行num_shards_乘法运算并添加my_shard_。
• IndexBlockDecoder现导出接口’AdvanceToDocid’，该接口返回首个≥“d”的文档ID索引。这使得扫描操作可基于本地文档ID进行，而非强制将每个本地文档ID转换为全局文档ID——当客户端为区块内每个索引调用GetDocid(index)时。
• 文档位置数据的解码现改为按需执行，而非在客户端请求区块内任意文档的位置数据时就提前完成整个区块的解码。
• 若解码的索引块在距页面边界4字节范围内结束，则将其复制到本地缓冲区。这确保我们始终能通过4字节加载操作加载位解码缓冲区，无需担心因mmap页面末尾溢出导致的段错误。
• 仅初始化各类评分数据结构的前 nterms_ 个元素，而非全部 MAX_TERMS 元素(某些情况下，我们曾对每个评分文档进行 20K 至 100K 数据的冗余 memset 操作)。
• 避免对计算值为0的中间评分值进行round_to_int转换及后续运算(后续运算仅会将memset的0覆盖为’0’，此类情况最为常见)。
• 将评分数据结构的边界检查改为调试模式断言。
